Here's a list of error codes on Triton ATMs and Tranax ATMs:


First Name:
Last Name:
Email:
Phone:
City:
State:
Interested in:

Comments:



Triton Error Codes

Error Code: 1
Definition: Time-out
Possible Cause:
1. Request has been sent. Time-out waiting for response or carrier was dropped. No characters were received. Time-out is typically 60 seconds.
2. Request has been sent. Time-out waiting for response or carrier was dropped. At least one character was received (ETX was never received). Time-out is typically 60 seconds.
3. EOT was received as first character after sending a NAK due to a bad response message.
Result:
No money is dispensed, screen and receipt display system unavailable.


Error Code: 3
Description: BCD NOANSWER
Possible Cause:
Possible may be a processor or telephone hardware problem.
Results:
No money is dispensed, screen and receipt display system unavailable


Error Code: 4
Description: ERROR IN MODEM DATA
Possible Cause:
Unexpected data received from processor in response to message.
Results:
No money is dispensed, screen and receipt display system unavailable.


Error Code: 5
Description: Connect 1200 Baud then lost carrier or connection. Host hung up.
Possible Cause:
1. Telephone line is not dedicated. (ATM is being used with another devices connected to the line.
2. Telephone line is noisy and in general has poor quality characteristics.
3. Baud rate set to high for telephone line conditions. Change baud rate settings.
4. Modem may be defective.
Results:
No money is dispensed, screen and receipt display system unavailable.


Error Code: 6
Description: BGD NODIALTONE
Possible Cause:
1. Used up all radial attempts and got No Dial Tone for each attempt.
2. Check local telephone line for proper operation.
3. Telephone hardware problems.
Results:
No money is dispensed, screen and receipt display system unavailable.


Error Code: 11
Description: No connect
Possible Cause:
1. Used up all radial attempt and got Busy Signal for each attempt or No Dial Tone for each attempt.
2. Got connected and never received ENQ within time-out period (14 Seconds).
Results:
No money is dispensed, screen and receipt display system unavailable.


Error Code: 13
Description: BGD DONE GOOD
Possible Cause:
Communication was normal, but response header does not match request.
Results:
No money is dispensed, screen and receipt display system unavailable.


Error Code: 14
Description: BGD DONE BAD
Possible Cause:
1. EOT was received as first character after the first request message was sent.
2. If EOT is received on subsequent attempts, then Error Code 1 is reported
Results:
No money is dispensed, screen and receipt display system unavailable.


Error Code: 17
Description: NO EOT
Possible Cause:
1. EOT from processor was not received within time out period.
2. Carrier was lost before receiving EOT.
Results:
No money is dispensed, screen and receipt display system unavailable.


Error Code: 18
Description: OVERFLOW
Possible Cause:
Received more characters, than expected after request causing modem buffer overflow.
Results:
No money is dispensed, screen and receipt display system unavailable.


Error Code: 48
Description: NO ANSWER
Possible Cause:
1. Modem response was good, but operation was not performed.
2. This is normally an internal terminal problem.
Results:
No money is dispensed, screen and receipt display system unavailable.


Error Code: 65
Description: Processor not communicating with the modem correctly
Possible Cause:
This is normally a terminal problem. The modem or the main board may cause the problem.
Results:
No money is dispensed, screen and receipt display system unavailable.


Error Code: 143
Description: PTDF (Processor Timeout Delay Failure) - ACS Code only.
Possible Cause:
A corrupt pin-working key may cause this problem.
Results:
No money is dispensed, screen and receipt display system unavailable.


Error Code: 32 (20h)
Description: Good operation
Recommended Action: No action required.


Error Code: 33 (21h)
Description: Feed Failure.
Recommended Action:
This error is usually associated with an empty note cassette or currency that is in “unfit” condition.
1. Refill the cassette as needed.
2. Inspect the cassette and feed path for currency that is stuck together or jammed.
3. If no jam is located, remove the first note from the cassette. Purge the dispenser. Do several test dispense operations. If the test dispenses are completed normally, and the return code are correct, clear all errors and place the cash dispenser in operation.
4. If the currency is in “fit “ condition and the error persists, consider replacing the cassette or the dispenser


Error Code: 34 (22h)
Description: Mistracked note at feed
Recommended Action:
This is a double detect fault.
1. Inspect the feed path for jammed currency. Remove jammed currency.
2. Inspected both the feed sensor and the double detect sensor to ensure they are not blocked and operating correctly. Clean the sensors a needed.
3. Turn the AC power OFF for a few seconds and then back ON to power cycle and reset the cash dispenser. Clear all errors and perform several test dispenses. If the test dispenses are normal and the status clears, place the cash dispenser in service. If the error persists, replace the dispenser.


Error Code: 35 (23h)
Description: Mistracked note at double detect.
Recommended Action: This status occurs when a note arrives at the double detect without being seen by the feed sensor.
1. Inspected both the feed sensor and the double detect sensor to ensure they are not blocked and operating correctly. Clean the sensors a needed.
2. Turn the AC power OFF for a few seconds and then back ON to power cycle and reset the cash dispenser. Clear all errors and perform several test dispenses. If the test dispenses are normal and the status clears, place the cash dispenser in service. If the error persists, replace the dispenser.


Error Code: 36 (24h)
Description: Mistracked note at exit.
Recommended Action:
This status occurs when a note is detected by the exit sensor when it should not have been. It can occur if there are notes already in the transport before the start of a transaction or if the exit sensor is blocked.
1. Verify that the diverter moves freely and is not binding. If the diverter has excessive binding or appears damaged, replace the dispenser.
2. Inspect the exit area to ensure nothing is blocking the exit sensor. Clean and verify the operation of the exit sensor. Replace the exit sensor if defective. Otherwise, replace the dispenser.
3. Turn the AC power OFF for a few seconds and then back ON to power cycle and reset the cash dispenser. Clear all errors and test the dispenser with a live transaction. It the status clears, place the cash dispenser in service. Otherwise, replace the dispenser.


Error Code: 37 (25h)
Description: Too long at exit.
Recommended Action:
This status is reported if the exit sensor is covered for a longer that allowed time for the current notes.
1. Inspect the note transport and delivery throat make sure all belts are on track and there are no documents jammed in the transport or exit areas. Place all belts on their respective rollers and gears. Clear the jammed documents.
2. Make sure that the exit sensor is clean and operation correctly.
3. Turn the AC power OFF for a few seconds and then back ON to power cycle and reset the cash dispenser. Clear all errors and test the dispenser with a live transaction. It the status clears, place the cash dispenser in service. Otherwise, replace the dispenser.


Error Code: 38 (26h)
Description: Blocked exit
Recommended Action:
This status appears if the exit sensor is covered or defective when the dispenser starts.
1. Inspect the note transport make sure all belts are on track and there is no currency jammed in the transport or exit areas. Place all belts on their respective rollers and gears. Clear the jammed documents.
2. Make sure that the exit sensor is clean and operation correctly.
3. Turn the AC power OFF for a few seconds and then back ON to power cycle and reset the cash dispenser. Clear all errors and test the dispenser with a live transaction. It the status clears, place the cash dispenser in service. Otherwise, replace the dispenser.


Error Code: 39 (27h)
Description: Too many notes
Recommended Action:
Clean the all sensors. Verify that all sensors are operation correctly. If all sensors are operation correctly, and the error persists, replace the replace the dispenser.


Error Code: 42 (2Ah)
Description: Transport error.
Recommended Action:
This is a timing wheel or timing wheel sensor error..
1. Inspect the dispenser to make sure all belts are on track and in good physical condition. Place all belts on their rollers and gears. If a belt displays excessive wear or damage you may be able to replace it. Otherwise, replace the dispenser.
2. Verify that the DC voltages to the dispenser are correct. Replace the power supply or dispenser DC power if either is defective.
3. Examine the timing wheel for physical defect. Make sure the electrical connections to the timing wheel sensor are secure and the time wheel sensor is clean. Replace the timing wheel or the timing wheel sensors if they are defective. Otherwise, it may be necessary to replace the dispenser.
4. Turn the AC power OFF for a few seconds and then back ON to power cycle and reset the cash dispenser. Clear all errors and test the dispenser by completing several TEST DISPENSES. If the status clears and the return code are normal place the cash dispenser in service. If these actions have no effect, replace the dispenser.


Error Code: 44 (2Ch)
Description: Double detect error.
Recommended Action:
This status is generated if the double detect is unable to calibrate. Probable cause for this error is a faulty or uncalibrated double detect module, or a jammed currency in the double detect.
1. Clear any jammed currency.
2. Turn the AC power OFF for a few seconds and then back ON to power cycle and reset the cash dispenser. Clear all errors and test the dispenser by completing several TEST DISPENSES. If the status clears and the return code are normal place the cash dispenser in service. If these actions have no effect, replace the dispenser.


Error Code: 45 (2Dh)
Description: Diverter error
Recommended Action:
This error occurs when the diverter is in the wrong position during a dispense.
1. Inspect the feed path for any jammed notes. Remove any jammed notes.
2. Turn the AC power OFF for a few seconds and then back on to power cycle and reset the cash dispenser. Clear the error. Purge the dispenser with the purge command. Complete several live dispenses to ensure the dispenser is working correctly. If the error persists, replace the dispenser.


Error Code: 46 (2Eh)
Description: Exit quantified
Recommended Action:
This status appears when the count at the exit is greater than the number of documents requested.
1. A mechanical error has occurred. It may be necessary to replace the dispenser.


Error Code: 47 (2Fh)
Description: Note missing at double detect
Recommended Action:
This status is generated if the double detect fails to detect a document already seen by the feed sensor.
1. Inspect the transport before the double detect for jammed currency. Clear the jammed currency.
2. Turn the AC power OFF for a few seconds and then back ON to power cycle and reset the cash dispenser. Clear all errors and test the dispenser by completing several TEST DISPENSES. If the status clears and the return code are normal place the cash dispenser in service. If these actions have no effect, replace the dispenser.


Error Code: 48 (30h) SDD Mechanism
Description: Reject rate exceeded.
Recommended Action:
This status is generated when there are 8 rejects during the current dispense. It is usually caused by attempting to dispense currency that is unacceptable or currency that has not been properly prepared.
1. Inspect the currency for excessive wear. Remove any unacceptable currency from the cassette.
2. Inspect the feed path for jammed currency. Remove any jammed currency.
3. Clear all error and purge the dispenser using the purge command.
4. Test the dispenser by completing several test dispenses with the test dispense command. If the error clears, put the cash dispenser back in service. If these actions have no effect, replace the dispensing mechanism.


Error Code: 48 (30h)
Description: Reject rate exceeded.
Recommended Action:
This status is generated when there are 10 rejects during the current dispense. It usually occurs when attempting to dispense documents that are unacceptable or documents that have not been prepared properly.
1. Inspect all documents for excessive wear. Remove any unacceptable notes from the cassette.
2. Inspect the feed path for jammed notes. Remove any jammed notes.
3. Clear all errors and PURGE the dispenser.
4. Test the TDM-100 by completing several Test Dispenses. If the error clears, put the cash dispenser in service. If these actions have no effect on dispenser operation, replace the dispenser mechanism.


Error Code: 49 (31h)
Description: Jam at exit
Recommended Action:
This status is generated when exit sensor is blocked.
1. Inspect the feed path for jammed currency. Remove any jammed currency.
2. Clear all error and purge the dispenser using the purge command.
3. Clean and verify the operation of the exit sensor. Replace the exit sensor if necessary.
4. Test the dispenser by completing several test dispenses with the test dispense command. It the error clears put the cash dispenser back in service. If these actions have no effect, replace the dispensing mechanism.


Error Code: 50 (32h)
Description: Interference recovery
Recommended Action:
Possible damage due to static discharge
1. Check the incoming power and dispenser mechanism for proper grounding.
2. Turn the AC power OFF for a few seconds and then back ON to power cycle and reset the cash dispenser.
3. Clear all errors and test the dispenser by completing several test dispenses. If the status clears and the return code are normal place the cash dispenser in service. If these actions have no effect, replace the dispenser.


Error Code: 51 (33h)
Description: Accountancy error
Recommended Action:
A mechanical failure has occurred. Replace the dispensing mechanism.


Error Code: 52 (34h)
Description: RAM error
Recommended Action:
A mechanical failure has occurred. Replace the dispensing mechanism.


Error Code: 53 (35h)
Description: EPROM error
Recommended Action:
A mechanical failure has occurred. Replace the dispensing mechanism.


Error Code: 54 (36h)
Description: Operation time-out
Recommended Action:
1. Check the incoming power and dispenser mechanism for proper grounding.
2. Turn the AC power OFF for a few seconds and then back ON to power cycle and reset the cash dispenser.
3. Clear all errors and test the dispenser by completing several test dispenses. If the status clears and the return code are normal place the cash dispenser in service. If these actions have no effect, replace the dispenser.


Error Code: 55 (37h)
Description: RAM corruption
Recommended Action:
A mechanical failure has occurred. Replace the dispensing mechanism.


Error Code: 56 (38h)
Description: Link error
Recommended Action:
1. Configuration jumpers may have been changed. Inspect jumper block LK5 on the dispenser main board. There should be no jumpers installed.
2. Turn the AC power OFF for a few seconds and then back ON to power cycle and reset the cash dispenser.
3. If the problem persists, replace the dispensing mechanism.


Error Code: 95
Description: Multiple cassettes of the same type
Recommended Action:
This is a multi-cassette dispenser error.
1. Verify that there is only one of each type of cassette installed in the dispensing mechanism.
2. If two or more of the same type cassette are installed, inject a new cassette ID into one of the cassettes that is different from the other cassette.


Error Code: 101 (65h)
Description: 2-second timeout waiting for pick. (Feed failure).
Recommended Action:
This error is usually associated with ""unfit"" currency or an empty cassette.
1. Refill the cassette as needed.
2. Inspect the feed path for currency that is stuck together or jammed. If no jams are found, remove the note closest the the pick rollers in the cassette.
3. Install the cassette. Purge the dispensing mechanism with the PURGE command from the DIAGNOSTICS function. Test the TDM-100 by completing several Test Dispenses. If the error clears, put the cash dispenser in service.
4. If the currency is in ""fit"" condition and the error condition persists, consider replacing the note cassette or the dispensing mechanism.


Error Code: 102 (66h)
Description: Error (Pick Motor over current)
Recommended Action:
1. Inspect the cassette and feed path for jammed currency. Clear any jammed currency.
2. Verify that all access panels are closed and secured. Purge the dispenser using the purge command.
3. Test the dispensing mechanism by completing several Test Dispenses. If the error does not occur again, put the cash dispenser in service.
4. If the error persists, replace the dispensing mechanism.


Error Code: 103 (67h)
Description: Thickness sensor unstable
Recommended Action:
Enter the diagnostic function and complete the “learn note thickness” command. Clear the error. Purge the dispenser using the purge command. Test the dispensing mechanism by completing several test dispenses. If the error does not occur again put the cash dispenser in service. If the error persists, replace the dispensing mechanism.


Error Code: 104 (68h)
Description: Unable to clear width sensor.
Recommended Action:
Remove the cassette and inspect for jammed currency in the width sensor and at the output of the cassette. The width sensor may be dirty. Clean the width sensor with compressed air. Purge the dispenser using the purge command. Test the dispensing mechanism by completing several test dispenses. If the error does not occur again, put the cash dispenser in service. If the error persists in may be necessary to replace either the cassette or dispensing mechanism.


Error Code: 105 (69h)
Description: Insufficient notes to learn from
Recommended Action:
There may be an insufficient number of notes in the cassette to complete the requested “learn note thickness” command. Put more currency in the cassette and repeat the “learn note thickness” command.


Error Code: 106 (6Ah)
Description: FIFO error
Recommended Action:
The dispensing mechanism may have corrupt software. Reset the cash dispenser. Purge the dispenser using the purge command. Test the dispensing mechanism by completing several test dispenses. If the error clears put the cash dispenser into service. If the error persists, replace the dispensing mechanism.


Error Code: 108 (6Ch)
Description: Unexpected note at double detect
Recommended Action: A note has been detected in the double detect sensor without being detected at the width sensor first.
1. Inspect the dispensing mechanism for of damaged components or broken wires.
2. Remove the cassette and visually inspect for loose or disconnected connectors on both the upper and lower width sensor printed circuit boards.
3. If there is no visible damage and the connectors are attached to the sensor boards the best course of action is to replace the dispensing mechanism.


Error Code: 109 (6Dh)
Description: Time-out at Exit sensor
Recommended Action:
1. Inspect for jammed currency in the feed path and at the Exit sensor. Remove any jammed currency.
2. Purge the dispenser using the purge command. Test the dispensing mechanism by completing several Test Dispenses.
3. If the error clears put the Cash Dispenser into service. Otherwise, replace the dispensing mechanism.


Error Code: 110 (6Eh)
Description: Trailing edge time-out at exit.
1. Inspect for jammed Currency in the feed path and at the Exit sensor. Remove any jammed currency.
2. Purge the dispenser using the purge command.
3. Test the dispensing mechanism by completing several test dispenses.
4. If the error clears put the cash dispenser into service. If the error persists, replace the dispensing mechanism.


Error Code: 111 (6Fh)
Description: Diverter timeout
Recommended Action:
1. Inspect for jammed currency at the diverter. Remove jammed currency.
2. Verify that all access panels are closed and secured. Clear the error. Test the dispenser by completing several test dispenses.
3. If the error clears, put the cash dispenser in service.
4. If these actions have no effect on dispenser operation, replace the dispenser mechanism.


Error Code: 112 (70h)
Description: Timeout waiting for leading edge at reject
Recommended Action:
A note that was expected to be seen by the reject sensor was not detected by the sensor.
1. Inspect for jammed currency in the transport path between the width sensors and the reject sensor. Remove jammed currency.
2. Verify that all access panels are closed and secured. Clear the error. Test the dispenser by completing several test dispenses.
3. If the error clears, put the cash dispenser in service.
4. If these actions have no effect on dispenser operation, replace the dispenser mechanism.


Error Code: 113 (71h)
Description: Timeout waiting for trailing edge at reject
Recommended Action:
1. Inspect for a jammed currency in the reject sensor.
2. Verify that all access panels are closed and secured. Reset the cash dispenser. Clear the error. Test the dispenser by completing several test dispenses.
3. If the error clears, put the cash dispenser in service.
4. If these actions have no effect on dispenser operation, replace the dispenser mechanism.


Error Code: 114 (72h)
Description: Exit blocked during purge
Recommended Action:
1. Inspect the dispensing mechanism for jammed currency at the exit sensor. Clear any jammed currency.
2. Clean the exit sensor using a soft brush and a vacuum cleaner. Reset the cash dispenser. Clear the error.
3. Test the dispenser by completing several test dispenses.
4. If the error clears, put the cash dispenser in service.
5. If these actions have no effect on dispenser operation, replace the dispenser mechanism.


Error Code: 115 (73h)
Description: Diverter timeout on purge
Recommended Action:
1. Inspect the dispensing mechanism for jammed currency at the diverter. Clear any jammed currency.
2. Make sure the shelf that the dispenser is mounted on is level and seated at all four corners.
3. Make sure the diverter moves freely.
4. Reset the cash dispenser. Clear the error.
5. Test the dispenser by completing several test dispenses. If the error clears, put the cash dispenser in service.
6. If these actions have no effect on dispenser operation, replace the dispenser mechanism.


Error Code: 118 (76h)
Description: Exit sensor blocked on start of dispense or learn
Recommended Action:
1. Inspect for jammed currency at the Exit. Remove jammed currency.
2. Verify that all access panels are closed and secured.
3. Use a soft brush abd vacuum cleaner to clean the exit sensor.
4. Clear the error. Test the dispenser by completing several test dispenses.
5. If the error clears, put the cash dispenser in service.
6. If these actions have no effect on dispenser operation, replace the dispenser mechanism.


Error Code: 119 (77h)
Description: Diverter in dispense position on start of dispense or learn
Recommended Action:
1. Inspect for jammed currency at the Diverter. Remove jammed currency.
2. Check the operation of the diverter solenoid.
3. Verify that all access panels are closed and secured. Clear the error. Test the dispenser by completing several test dispenses.
4. If the error clears, put the cash dispenser in service.
5. If these actions have no effect on dispenser operation, replace the dispenser mechanism.


Error Code: 122 (7Ah)
Description: Unexpected note at exit
1. Purge the dispenser using the purge command from diagnostic menu.
2. Test the dispenser by completing several test dispenses. If the error clears, put the cash dispenser in service.
3. If these actions have no effect on dispenser operation, replace the dispenser mechanism and/or the note cassette.


Error Code: 124 (7Ch)
Description: Diverter moved to exit position during reject purge
Recommended Action:
1. Inspect for a currency jam at the diverter.
2. Verify that the diverter moves freely.
3. Test the dispenser by completing several test dispenses.
4. If the error clears, put the cash dispenser in service.
5. If these actions have no effect on dispenser operation, replace the dispenser mechanism.


Error Code: 125 (7Dh)
Description: Initial status check failed
Recommended Action:
1. Reset the cash dispenser. Clear the error.
2. If the error persists replace the dispensing mechanism.


Error Code: 126 (7Eh)
Description: Diverter moved to reject position during dispense
Recommended Action:
Inspect for a note jam at the diverter. Verify that the diverter moves freely. Test the dispenser by completing several test dispenses. If the error clears, put the cash dispenser in service. If these actions have no effect on dispenser operation, replace the dispenser mechanism.


Error Code: 128
Description: Error in reply from the dispenser mechanism
Recommended Action:
1. Verify that the power supply is operating and the DC voltages being supplied to the main board and dispenser are correct. Reseat connectors or replace the power supply as needed.
2. Verify that main board to electronic journal and the electronic journal to dispenser cables securely seated at both ends of the cable. The cables may be defective.
3. Other components that may cause this error are the main board or the dispensing mechanism.


Error Code: 129
Description: No response from the dispenser mechanism.
Recommended Action:
See the recommended action for error code 128.


Error Code: 130
Description: Command not acknowledged by the dispenser mechanism.
Recommended Action:
See the recommended action for error code 128.


Error Code: 131
Description: CTS (Clear To Send) line from the dispenser is not active.
Recommended Action:
See the recommended action for error eode 128.


Error Code: 132
Description: Error code reports bad doubles detect in last dispense.
Recommended Action:
Remove the cassettes and inspect the dispenser's feed path for jammed documents and other debris in the double detect assembly. Open all access panels and inspect for jammed documents and other debris. Install the cassette. Reset the cash dispenser by turning OFF the AC power switch for a few seconds and switching it back ON. Clear the error. Purge the dispenser using PURGE command. Complete several Test Dispenses to verify correct operation. If the problem persists, replace the dispensing mechanism.


Error Code: 133
Description: +5 VDC not present on carrier detect.
Recommended Action:
See the recommended action for error code 128


Error Code: 134
Description: Exit blocked as reported by error code check.
Recommended Action:
Inspect the feed path exit sensor for jammed documents and broken components. The exit sensor may be dirty. Clean as needed with compressed air. Reset the cash dispenser by turning OFF the AC power switch for a few seconds and switching it back ON. Clear the error. Purge the dispenser with the PURGE command. Verify correct operation with a live transaction. If the problem persists, replace the dispensing mechanism.


Error Code: 135
Description: Feed sensor blocked.
Recommended Action:
Inspect the feed path and feed sensors for jammed documents and broken components. The feed sensors may be dirty. Clean as needed with compressed air. Reset the cash dispenser by turning OFF the AC power switch for a few seconds and switching it back ON. Clear the error. Purge the dispenser with the PURGE command. Complete several Test Dispenses to verify correct operation. If the problem persists, replace the dispensing mechanism.


Error Code: 136
Description: Modem initialization failed.
Recommended Action:
Reset the cash dispenser by turning OFF the AC power switch for a few seconds and switching it back ON. If the problem persists, remove the main board and replace the modem. If replacing the modem does not correct the problem, replace the main board.


Error Code: 138
Description: Printer failed while printing to the receipt printer.
Recommended Action:
Verify that the Printer has paper in it. Replenish paper as needed. Refer to Section 4 of the RL5000 Installation and Service Manual or the RL5000 Quick Reference Guide for instructions. Release the printer locking screw. Open the printer and verify that there are no jams in the printer or the paper path. Verify the blue lever on the left side of the printer in the print position. Inspect the cable supplying DC power from the power supply to the printer. Make sure it is connected to CN1 on the printer control board. Verify that all DC voltages applied to the printer control board are correct. If the voltages are not within tolerance, you may need to replace the cable or power supply. Inspect the printer data cable for damage. Make sure it is seated at the main board at J15 and at the printer control board at CN6. Inspect the cables connected to CN2, CN3, CN4, and CN5. Make sure they are seated at the printer control board and not damaged. If the voltages are correct, and the cables are undamaged and correctly connected, causes of this error may be a defective cable, a defective printer, printer control board, or the main board.


Error Code: 139
Description: Printer controller not responding to commands.
Recommended Action:
See recommended action for error code 138.


Error Code: 140
Description: Time-out waiting for printer to be ready.
Recommended Action:
See recommended action for error code 138.


Error Code: 141
Description: Paper jam reported by the controller during error code check.
Recommended Action:
Release the Printer Locking screw. Open the Printer Bracket and verify that there are no jams in the printer or the paper path. Verify the blue lever on the left side of the printer in the print position. Check the DC voltages supplied to the Printer. If the voltages are correct and the blue lever is in the print position, the most likely causes of the error are the printer, printer control board, or the main board.


Error Code: 142
Description: Dispenser returns bad command error.
Recommended Action:
See the recommended action for error code 128.


Error Code: 143
Description: PTDF error.
Recommended Action:
This error code will occur only in cash dispensers running ACS terminal software. This problem may be caused by a corrupt pin working key. Check with the processor.


Error Code: 144
Description: No reply from the electronic journal.
Recommended Action:
Inspect main board to Electronic Serial communication cable for damage. Make sure the connectors are seated securely on the dispensing mechanism and on the main board. If it is necessary to check continuity of the cable assembly, refer to Appendix B for pinout of the cable assembly. Verify that the DC voltages supplied to the dispensing mechanism are correct. If the cable is undamaged and DC voltages are correct, the main board, electronic journal, or dispenser may be defective.


Error Code: 145
Description: Error in reply from the electronic journal.
Recommended Action:
See the recommended action for error code 144.


Error Code: 146
Description: No reply from command to electronic journal.
Recommended Action:
See the recommended action for error code 144.


Error Code: 147
Description: Error in reply from electronic journal.
Recommended Action:
See the recommended action for error code 144.


Error Code: 148
Description: Write to electronic journal failed.
Recommended Action:
See the recommended action for error code 144.


Error Code: 149
Description: Read from electronic journal failed.
Recommended Action:
See the recommended action for error code 144.


Error Code: 150
Description: Error code command to journal failed.
Recommended Action:
See the recommended action for error code 144.

Error Code: 151
Description: Electronic Journal Full.
Recommended Action:
Open the control panel and verify that there is sufficient paper on the roll to print a complete journal (32.768 entries). Replace paper as need-ed. Enter the management functions and complete the print journal command.

Error Code: 152
Description: Electronic journal corrupt.
Recommended Action:
See the recommended action for error code 144.

Error Code: 153
Description: Electronic journal mode.
Recommended Action:
See the recommended action for error code 144.

Error Code: 154
Description: Unknown electronic journal error code.
Recommended Action:
See the recommended action for error code 144.

Error Code: 155
Description: Electronic journal modify record failure.
Recommended Action:
See the recommended action for error code 144.


Error Code: 156
Description: Cassettes not in service.
Recommended Action:
Enter management functions and make sure that the cassettes are programmed and placed in service.

Error Code: 157
Description: Format command to electronic journal failed.
Recommended Action:
See the recommended action for error code 144.

Error Code: 158
Description: Format command to electronic journal failed.
Recommended Action:
See the recommended action for error code 144.

Error Code: 159
Description: Electronic journal test feature failed.
Recommended Action:
See the recommended action for error code 144.

Error Code: 160
Description: Electronic journal set featured failed.
Recommended Action:
See the recommended action for error code 144.

Error Code: 161
Description: Electronic journal clear feature failed.
Recommended Action:
See the recommended action for error code 144.

Error Code: 162
Description: Electronic Journal get serial number failed.
Recommended Action:
See the recommended action for error code 144.

Error Code: 163
Description: Terminal did not answer (Triton Connect error)
Recommended Action:
This error is not displayed at the cash dispenser. The Triton Connect Host Computer generates the error when a terminal does not respond to a telephone call from the Triton Connect Host Computer. The cash dispenser may be turned OFF, or the telephone line is shared with some other device that connects to the line before the cash dispenser. Additionally, the Triton Connect feature may be disabled at the cash dispenser. This problem may also be caused by a defective modem.

Error Code: 164
Description: Terminal did not return call. (Triton Connect error)
Recommended Action:
This error is not displayed at the cash dispenser. The Triton Connect Host Computer generates this error when a terminal does not make a call to the Triton Connect Host Computer as requested. Replace the modem module.

Error Code: 165
Description: Electronic journal not present.
Recommended Action:
See the recommended action for error code 144.

Error Code: 166
Description: Bad dispense.
Recommended Action:
Open the Security Cabinet and inspect the cash dispenser for broken parts. Replace the dispenser if it is broken. Check for and clear any foreign debris the note path. Reset the cash dispenser. Replace the dispenser if the error persists.


Error Code: 183
Description: Receipt paper low
Recommended Action:
Install a new roll of paper if needed. If this does not correct the problem, verify that the paper low sensor is correctly attached to the paper bracket and it is connected to the printer controller PCB. The paper low sensor may be dirty and require cleaning. Otherwise, the possible causes of the problem may be a defective paper low sensor, or a defective printer control PCB. A temporary fix to this problem may be to set the LOW RECEIPT PAPER parameter to IN SERVICE so that the terminal software does not read the input from the low paper sensor. When this is done, the terminal will operate normally until it is completely out of paper. Then it will go "Out of Service" for an Error 195 "Out of Paper".

Error Code: 185
Description: Telephone number not configured
Recommended Action:
Enter the Management Functions and configure the primary telephone number.

Error Code: 186
Description: Bill size not configured
Recommended Action:
Default value is factory set to $0.00. Allowable bill sizes are 5, 10, 20, 50, and 100. Enter the management functions and configure the multiple amount parameter.

Error Code: 187
Description: Maximum withdrawal not configured.
Recommended Action:
Enter management functions and configure the maximum amount. The maximum withdrawal cannot exceed 50 time the denomination of the of the of the bill size in the cassette.

Error Code: 188
Description: PIN Working key not configured.
Recommended Action:
Enter management functions and configure the pin working key.

Error Code: 189
Description: Terminal ID not configured.
Recommended Action:
Enter the management function and configure the terminal ID correctly.

Error Code: 190
Description: Pin Master key not configured.
Recommended Action:
Enter management functions and enter the pin master key.

Error Code: 192
Description: Communications error.
Recommended Action:
Enter management functions and verify that all terminal parameters have been set correctly. Verify that the telephone line is operational. Reset the cash dispenser and clear the error. Other possible causes may be a defective modem or main board

Error Code: 193
Description: The baud rate setting for electronic journal failed.
Recommended Action:
Inspect the electronic journal to make sure is it the correct part number. Reset the cash dispenser and clear the error. If the error persists, replace the Electronic Journal.

Error Code: 194
Description: An attempt to dispense bills has been made when the cassettes are unlocked.
Recommended Action:
This error may occur anytime that a cassette is removed from the cash dispenser with the AC Power ON. Make sure that the cassettes are installed and locked before performing a test dispense or live transaction.

Error Code: 195
Description: Receipt printer out of paper.
Recommended Action: Replenish the paper. Reset the cash dispenser and clear the error. Make sure that the ribbon cable from the docking station to the low paper sensor assembly is fastened at both ends of the cable and the orientation of the cable is correct. If the error persists, possible causes of the problem may be the low paper sensor assembly, the docking station, the main board, or cables.

Error Code: 196
Description: Card reader error.
Recommended Action:
Inspect the card reader assembly. Make sure that there is no foreign material in the card slot. Clean the card reader assembly with a cleaning card. Make sure the ribbon cable from the docking station to the card reader is fastened at both ends of the cable and the orientation of the cable is correct. Reset the cash dispenser and clear the error. If the error persists, replace the card reader.

Error Code: 203
Description: SPED keypad is not replying to main board.
Recommended Action:
Error code valid only for units with SPED keypad device installed. Make sure the battery is seated secure in the battery holder. Make sure the tamper screw is secure to the SPED module. Reset the cash dispenser and clear the error. If the error persists, replace the SPED keypad module.

Error Code: 205
Description: SPED keypad reported tamper condition.
Recommended Action:
Error code valid only for units with SPED keypad device installed. Make sure the battery is seated secure in the battery holder. Make sure the tamper screw is secure to the SPED module. Reset the cash dispenser and clear the error. If the error persists, replace the SPED keypad module.

Error Code: 206
Description: SPED keypad could not perform a successful command within SPED MAX_ATTEMPTS tries.
Recommended Action:
Error code valid only for units with SPED keypad device installed. Reset the cash dispenser and clear the error. If error persists, replace the SPED keypad module.

Error Code: 207
Description: SPED not detected.
Recommended Action: This Error Code is valid for units with SPED keypad device installed. Check the cable and connections from the docking station to the SPED board. Verify that the SPED board has the correct DC voltages applied to it. If the DC voltages applied to the SPED board correct and the cables are in good condition and seated properly, replace the SPED board.

Error Code: 300(30h)[0]
Description: Successful Command
Recommended Action:
The dispenser sends this error code when a command has been successfully executed. This error code will appear in the electronic journal as code 300 indicating the successful completion of a transaction. When performing a PURGE or TEST DISPENSE operation the return code will be "0" in the first digit returned by the dispenser. It will be display as the hexadecimal number "30" when running the dispenser with the NMD test software.

Error Code: 301(31h)[1]
Description: Low level in cassette.
Recommended Action:
This error code is returned by the dispenser when the number of notes in one or more of the cassettes is below a preset level, indicating the low level sensor in the note cassette has been activated. This occurs when the currency in any cassette reaches a thickness of approximately 25-35 mm. This is a warning message. It will not place the cash dispenser "Out of Service". This condition is also displayed on the configuration summary printout under "dispenser" as a lower case a, b, c, or d for the cassette in the low currency condition. Otherwise, the error code for cassettes not in a low currency condition would normally be upper case characters A, B, C, or D. Remove and fill the affected cassette using normal procedures. Refilling may be delayed for several transactions if the error code is the first warning that the cassette is nearly empty. However, actions to fill the cassette should be taken as soon as possible.

Error Code: 302(32h)[2]
Description: Empty Cassette.
Recommended Action:
This error code is generated when a cassette is emptied during a dispense operation and does a partial dispense. The cash dispenser will attempt to complete the transaction from other cassettes. If the requested amount cannot be dispensed, the customer will receive the cash that can be dispensed. The transaction will be completed with the customers' receipt indicating the amount of cash actually received. The cash dispenser will then attempt to complete a Reversal Transaction to notify the financial institution of the error. This error will not put the cash dispenser "Out of Service". The cash dispenser will only be placed "Out of Service" when all cassettes are empty. Remove and refill the affected cassette using normal replenishment procedures.

Error Code: 303(33h)[3]
Description: Lifts are down.
Recommended Action:
This error code is generated when a cassette is not open and any command other than open cassettes, reset, and close cassettes are sent to the system. It is feasible that this error code could be generated even if the lifts are in the up position. This will occur if the machine is switched off and on during normal daily operation. This is done to indicate that the power has been off. Clear this error code by restarting the cash dispense or by unlocking and locking the cassettes. If the error recurs, a faulty cassette, note feeder or CMC module may be cause the problem.

Error Code: 304(34h)[4]
Description: Rejected notes.
Recommended Action:
This error code indicates that notes were rejected during the transaction or test dispense operation. This is a warning message there is no action required.

Error Code: 305(35h)[5]
Description: Diverter Failure.
Recommended Action:
This error code indicates that the system has recognized a document intended for the reject vault has reached the note transport sensor. The most probable cause is either mechanical or electrical failure of the note diverter in the note transport module. This error will place the cash dispenser "Out of Service". Inspect the note diverter in the note transport module. Verify that there are no documents jammed in the note diverter area. Make sure the note diverter moves freely. Check to make sure that cables connecting the note transport and the CMC module are not damaged. Make sure all connectors attached to the CMC are seated in their receptacles. Remove and empty the reject vault. Install the Reject Vault. PURGE the dispensing mechanism. Complete several test dispenses. If the error does not repeat again, complete a live dispense to verify the note diverter moves the currency to the exit position. If the error reoccurs the most likely causes of the problem may be note transport or CMC.

Error Code: 305(35h)[5]
Description: Diverter Failure.
Recommended Action:
This error code indicates that the system has recognized a document intended for the reject vault has reached the note transport sensor. The most probable cause is either mechanical or electrical failure of the note diverter in the note transport module. This error will place the cash dispenser "Out of Service". Inspect the note diverter in the note transport module. Verify that there are no documents jammed in the note diverter area. Make sure the note diverter moves freely. Check to make sure that cables connecting the note transport and the CMC module are not damaged. Make sure all connectors attached to the CMC are seated in their receptacles. Remove and empty the reject vault. Install the reject vault. PURGE the dispensing mechanism. Complete several test dispenses. If the error does not repeat again, complete a live dispense to verify the note diverter moves the currency to the exit position. If the error reoccurs the most likely causes of the problem may be note transport or CMC.

Error Code: 307(37h)[7]
Description: Transmission Error.
Recommended Action:
This error code occurs when the message received by the dispenser is incorrect. The reason that the error code is generated is the detection of an incorrect LRC character or a parity error. Inspect all communication cables to make sure they are not damaged and are properly connect to their termination points. Restart the cash dispenser. Reset the dispenser and try to complete a test dispense. If the error code is reported again, replace the CMC module. Otherwise, put the cash dispenser into service.

Error Code: 308(38h)[8]
Description: Illegal Command or Command Sequence.
Recommended Action:
This error occurs when the logical sequence of the commands sent to the dispenser is not the one expected by the system. Examples of this are two move commands sent one after another or a deliver command that is sent without a previous move command. Inspect all communication cables to make sure they are not damaged. Make sure all cables are properly connected. Reset the dispenser and try to resend the command that caused the error code. If the error code is reported again, replace the CMC module.

Error Code: 309(39h)[9]
Description: Jam in Note Qualifier.
Recommended Action:
This error code is generated when the note transport sensor does not detect a note that was detected by the note qualifier. This may be due to jammed documents in the transport path between the note qualifier and the note diverter. This error code will place the cash dispenser "Out of Service". Inspect the documents in each cassette to insure they are in fit condition. Make sure that note qualifier and the note transport modules are mechanically aligned. Open all access panels and inspect for jammed documents in note path between the note qualifier and note transport. Remove the jammed documents as needed. Inspect the note qualifier and note transport for broken components (i.e. belts, gears, cables, or sensors). Inspect the note diverter for proper operation and damage. Replace the note qualifier or note transport if the problem persists.

Error Code: 310(3Ah)[:]
Description: Cassette not properly installed.
Recommended Action:
This error code occurs when documents are requested from a cassette that is not present or is not open. This error code will place the cash dispenser in an "Out of Service" condition. Verify the physical presence of each cassette. If present, "unlock" and remove each cassette from its feed channel. Put the cassettes back into its feed channel. Lock the cassettes. Clear the error and perform a test dispense. If the error is repeated, proceed to the next paragraph. If the error does not show again put the cash dispenser back into service. Verify that the identity of each cassette can be read through read cassette ID function (See the 5000 Cash Dispenser Configuration Manual). Cassettes with no identity must be injected with a new cassette ID (See the 5000 Cash Dispenser Configuration Manual). If a cassette cannot be injected with a new ID, verify that the cable between the top feed channel and the CMC is in good condition and connected at both ends. Try to inject an ID into another cassette. If the inject cassette ID function works on a different cassette. Then the original cassette is faulty. If the inject cassette ID function fails on a different cassette the CMC is defective.

Error Code: 315(3Fh)[?]
Description: Reject vault not properly installed.
Recommended Action:
This error code is generated when the reject vault is not present or not properly installed. Attempting to operate the cash dispenser without the reject vault will normally cause it to go to an "Out of Service" condition. Make sure the reject vault is installed correctly. Inspect the reject vault present sensor visually for proper operation. Use the cash dispenser diagnostic functions to check the electrical operation of the sensor. If the sensor is properly connected and operating correctly the CMC module may be defective. If the sensor is not operating normally, replace the note transport module.

Error Code: 318(42h)[B]
Description: Too many notes requested.
Recommended Action:
This error code occurs while running the dispenser on the NMD test software and when too many notes are requested during a dispense command. The maximum number of notes that can be dispensed from the dispenser during a transaction is defaulted to fifty. Retry the test operation and request fifty or fewer notes.


Error Code: 319(43h)[C]
Description: Jam in note transport.
Recommended Action:
This error code is generated when a document from a note feeder fails to reach the note qualifier with in a specified time. This failure may be caused by a blockage in the transport path between the Note Feeder and the note qualifier, or if a document passes through the note qualifier unseen. This error code will cause the cash dispenser to go "Out of Service". Check the cassettes. Make sure they are not overfilled. The recommended capacity is 1850 documents. Make sure the documents are fit condition. Open all access panels and remove any jammed documents from the transport path. Inspect the note feeders and note qualifier for damage. Restart the cash dispenser. Reset the error. Complete several test dispenses. If the test dispenses are normal and the error does not show again, the cash dispenser may be returned to service. If the error recurs, change the note feeder for the affected channel.

Error Code: 320(44h)[D]
Description: Reject cassette almost full.
Recommended Action:
This error code is generated when the number of reject events exceeds 37 events. Error code 320 will not put the cash dispenser "Out of Service. It is not displayed directly to the operator or customer. The error code will be sent to the Triton Connect host if Triton Connect feature is enabled. It will also be stored as part of the transaction data in the electronic journal. The reject vault should be emptied as soon as possible in order to avoid an "Out of Service" condition that occurs when the number of reject events reaches 50. The reject event counter can be reset by removing the reject vault from the dispenser and then putting it back into the dispenser.

Error Code: 321(45h)[E]
Description: Cassette data corrupted.
Recommended Action:
This error code is generated when there is a checksum error in data stored in the note cassette. Program the cassette by injecting a new cassette ID into the cassette. If injecting a new cassette ID into the cassette does not correct the problem, replace the cassette.

Error Code: 322(46h)[F]
Description: Main motor failure
Recommended Action:
Error code 322 is generated when the main motor fails to reach normal speed with in a specified time, or if there are several pulses missing from the transport clock wheel (timing wheel) in one transaction. This error code causes an "Out of Service" condition. Open all access panels and remove any jammed documents from the transport path. Verify the documents are fit for dispensing. Inspect the note qualifier for any damage (i.e. broken belts, broken gears, disconnected or damaged cables, broken timing wheel etc.). Make sure all access panels are closed. Restart the cash dispenser and reset the error. Complete several test dispenses. If cash dispenser operates normally when performing the test dispense function, put the cash dispenser in service. It the error code repeats, verify the power supply output voltages are within expected values. Replace the power supply if necessary. If the power supply if operating normally, replace the note qualifier to correct the problem.

Error Code: 325(49h)[I]
Description: Note qualifier faulty
Recommended Action:
Error code 325 is generated when the double detect sensors in the note qualifier can not be calibrated, or when the gain value cannot be adjusted when learning a new documents. Verify that the cable that connects the double detect module to the CMC module is undamaged and connected at both ends. Make sure the access panel on the bottom of the note qualifier is closed and locked in position. Carefully remove the double detect module from the note qualifier. Use clean compressed air to remove any dust or dirt from the sensor lenses. Carefully install the double detect module into the note qualifier. Make sure all connections between the double detect module and the CMC are seated properly. If at any time during the following checks, the ""faulty note qualifier"" error code recurs. It will be necessary to replace the note qualifier. Restart the cash dispenser. Reset the error the error code. If it clears, initiate the learn note thickness operation. Perform a test dispense. If cash dispenser operates normally, it will pick from seven to fifteen notes from each cassette to calibrate the double detect to the document in each of the cassettes. Then it will complete the test dispense function. A normal return code for this test dispense operation is "4 1 1 1 1" for a four cassette dispenser. If the operation is normal, you may put the cash dispenser in service. If these check are not properly completed replace the note qualifier.

Error Code: 326(4Ah)[J]
Description: Note feed sensor failure.
Recommended Action:
This error code is generated when there is a sensor error in one or more of the note feeders or when there is a document jammed in the note feeder exit sensor. Make sure there are not any documents jammed at any of note feeder exit sensors. Check the calibration value for the pressure, empty, and exit sensors. If any sensor is out of its calibration limits, clean all of the sensors and attempt to do a transaction. If error code reoccurs, replace the note feeder module.

Error Code: 329(4Dh)[M]
Description: Notes in delivery throat.
Recommended Action:
An attempt to feed or dispense documents has been made when there is a note in the note transport throat. Remove any documents blocking the throat opening. Make sure the diverter is not jammed. Inspect the note transport for damage and verify that all connectors are plugged into their respective receptacles. Use the reject channel error code function to verify the operation of the sensors on the note transport module. Clean the sensors in the note transport a needed. Restart the cash dispenser. Reset the error code. Perform the test dispense function several times (two or three). Complete a live transaction. If the error does not show again put the cash dispenser into service. If the error code returns, replace the note transport module.

Error Code: 330(4Eh)[N]
Description: Communication timeout.
Recommended Action:
This error is reported when the transmission of each one of the characters in the command string is not completed within the time restriction imposed by the electrical interface. Inspect all cables for damage. Verify that the both ends of each cable are securely connected to its termination points. This problem may be caused by incompatibilities between terminal software and dispensing mechanism software. Check with Triton Systems Technical Support for known software incompatibilities.

Error Code: 332(50h)[P]
Description: Cassettes may have been changed.
Recommended Action:
This error code is generated when a movement command is sent before read cassette ID command after the cassettes, including the reject vault are removed. This is error code will set an “Out of Service” condition. Verify that each cassette is placed in its designated feed channel. Complete the test receipt printer function to determine which if any of the cassettes are not responding. If a cassette is not responding it may be necessary to inject a new identity into the cassette by completing the inject new cassette ID command. A defective cassette may also cause this problem.

Error Code: 333(51h)[Q]
Description: Reject vault full.
Recommended Action:
This error code is produced when the single reject event counter exceeds 50 reject events or the bundle reject event counter exceeds 250 notes. This error code will cause an “Out of Service” condition. Remove all documents from the reject vault. To clear the error code, the reject vault must be removed and inserted with the power on. This will reset the reject event counters.

Error Code: 339(57h)[W]
Description: Error in throat.
Recommended Action:
This error code is reported by the dispensing mechanism when a document is jammed in the throat sensor during a live dispenses or when a reset is performed. Make sure all cables between the note transport and the other units are undamaged and securely seated at their termination point. Check the operation of all sensors in the note transport module. Inspect the diverter area to make sure that it is not blocked and that it moves freely. Make sure that the access panels before and after the diverter are closed and secured in place. Remove any documents from the tote transport. Restart the cash dispenser. Reset the error code. Perform a live transaction. If the cash dispenser operates normally put it back in service. If the error code persists, replace the note transport module.

Error Code: 343(5Bh)[[]
Description: Sensor error or sensor covered.
Recommended Action:
This error is produced when a sensor in note transport module is not working correctly during an internal self-test preceding the movement commands. Inspect all cables for damage. Make sure that all cables are securely fastened to their termination points. Open the access panels on the note transport and remove any documents that may be in the transport path. Access the error code command to determine if any sensors in the reject channel are dirty of defective. Clean the dirty sensor, or replace the note transport as needed. Restart the cash dispenser. Reset the error. Perform a live transaction. If the cash dispenser operates normally put it in service. If the problem persists, replace the note transport module.

Error Code: 348(60h)[']
Description: Dispenser internal error.
Recommended Action:
This error code is reported when an internal error occurs in the dispenser. The most likely cause is internal communication problems within the dispenser. Inspect all cables for possible damage. Ensure that each cable is securely fastened to its termination point. Restart the cash dispenser. Reset the error. If the response to the RESET command indicates a successful execution, put the cash dispenser back in service. If the error code is reported again, it may be necessary to replace the CMC or one of the note feeder controllers.

Error Code: 349(61h)[a]
Description: Cassette lock faulty.
Recommended Action:
This error code is generated when the LIFTS UP command fails to open a note cassette to the operating position. Verify that the currency is properly installed in the cassette. If necessary, reload the currency in the cassette. If the problem remains after reloading the cassette, replace the cassette, the denomination extension, or the note feeder controller associated with the cassette causing the problem.

Error Code: 351(63h)[c]
Description: Module needs service.
Recommended Action:
This error code is generated by the dispensing mechanism when the calibration value for at least one of the sensors in any of the note feeders has exceeded the upper limits of its calibration range. Use the diagnostic functions or NMD test software to determine if a note feeder has a faulty or dirty sensor. Remove each note feeder module from the dispensing mechanism and clean their associated empty, pressure and exit sensors with clean compressed air. Install the note feeders and recheck their operation to determine if the error code has been cleared. If the error code has been cleared, the cash dispenser can be put back in service. If the error code is repeated, replace the note feeder or note feeder controller for the affected feed channel.

Error Code: 353(65h)[e]
Description: No message to resend.
Recommended Action: This error code may indicate a power loss/firmware restart has occurred at the dispenser controller and no information could be retrieved. Restart the cash dispenser. Reset the error. Perform several test dispenses. If the cash dispenser operates normally while performing a test dispense, put it back into service. If the error code recurs, replace the CMC module.

Error Code: 356(68)[h]
Description: Error in note transport.
Recommended Action:
This error code will be generated when the following conditions occur: 1. When the note is stuck in the note transport sensor. 2. When the note is stuck in between the note transport sensor and the throat. Inspect the note transport sensor for blockage. If the sensor is blocked, remove the blockage. Clean the sensors if needed. Restart the cash dispenser. Reset the error. If the error code continues, replace the note transport module. Otherwise, put the cash dispenser into service.

Error Code: 357
Description: Dispenser data size error.
Recommended Action:
Restart the operating system. Clear terminal error code. Replace the dispenser is the error persists.

Error Code: 358
Description: Dispenser device read error.
Recommended Action:
Restart the operating system. Clear terminal error code. Replace the dispenser is the error persists.

Error Code: 359
Description: Dispenser device record error.
Recommended Action:
Restart the operating system. Clear terminal error code. Replace the dispenser is the error persists.

Error Code: 360
Description: Dispenser invalid return ID.
Recommended Action:
Restart the operating system. Clear terminal error code. Replace the dispenser is the error persists.

Error Code: 361
Description: Dispenser sequence error.
Recommended Action:
Restart the operating system. Clear terminal error code. Replace the dispenser is the error persists.

Error Code: 362
Description: Dispenser device write error.
Recommended Action:
Restart the operating system. Clear terminal error code. Replace the dispenser is the error persists.

Error Code: 363
Description: Dispenser device not found
Recommended Action:
Restart the operating system. Clear terminal error code. Replace the dispenser is the error persists.

Error Code: 364
Description: Dispenser device offline.
Recommended Action:
Restart the operating system. Clear terminal error code. Replace the dispenser is the error persists.

Error Code: 365
Description: Dispenser BCC error.
Recommended Action:
Restart the operating system. Clear terminal error code. Replace the dispenser is the error persists.

Error Code: 366
Description: Dispenser cassettes disabled.
Recommended Action:
Access management functions and enable cassettes.

Error Code: 367
Description: Dispenser communication error.
Recommended Action:
Check the dispenser data and power cable connections. Restart the operating system. Clear terminal error code. Replace the dispenser is the error persists.

Error Code: 368
Description: Dispenser cannot dispense the request.
Recommended Action:
Requested amount may exceed the dispensers one time limit. Enter a smaller value. If error persists, replace the dispenser mechanism.

Error Code: 369
Description: Dispenser device reset.
Recommended Action:
Check data and power connections to the dispenser device. Clear terminal error code. If error persists, replace the dispenser mechanism.

Error Code: 370
Description: Dispenser - SDD EOT error.
Recommended Action:
Check data and power connections to the dispenser device. Clear terminal error code. If error persists, replace the dispenser mechanism.

Error Code: 371
Description: Dispenser SDD com error header-trailer.
Recommended Action:
Check data and power connections to the dispenser. Clear terminal error code. If error persists, replace the dispenser mechanism.

Error Code: 372
Description: Dispenser item value error
Recommended Action:
Clear terminal error code. If error persists, replace the dispenser mechanism.

Error Code: 373
Description: Dispenser machine not opened.
Recommended Action:
Access the management functions menu and lock all cassettes. Verify that all cassettes used are in service.

Error Code: 374
Description: Dispenser rejected cheque.
Recommended Action:
Clear terminal error code. If error persists, replace the dispenser mechanism.

Error Code: 375
Description: Dispenser invalid request.
Recommended Action:
Clear terminal error code. If error persists, replace the dispenser mechanism.

Error Code: 376
Description: Dispenser multiple device error.
Recommended Action:
Restart operating system. Clear terminal error code. If error persists, replace the dispenser mechanism.

Error Code: 377
Description: Dispenser device error.
Recommended Action:
Restart operating system. Clear terminal error code. If error persists, replace the dispenser mechanism.


Error Code: 379
Description: Dispenser unknown error code.
Recommended Action:
Restart operating system. Clear terminal error code. If error persists, replace the dispenser mechanism.

Error Code: 382
Description: Dispenser cassettes disabled (ALL).
Recommended Action:
Enter management functions menu and place the cassette(s) in service.

Error Code: 383
Description: Dispense cassettes low (ALL).
Recommended Action:
All cassettes have reached low cash level. Reload cassettes. Clear terminal error code.

Error Code: 384
Description: Dispenser cassettes empty (ALL).
Recommended Action:
All cassettes report no notes. Reload cassettes. Clear terminal error code.

Error Code: 385
Description: Dispenser offline, no reject vault and not hoppers.
Recommended Action:
Verify that the dispenser mechanism has data and power cable connected. Verify power is applied to the dispenser.

Error Code: 386
Description: Dispenser offline - no hoppers.
Recommended Action:
The hoppers are not detected. Check the computer area network connectors in the dispenser. Restart operating system. Clear terminal error code. If error persists, replace the dispenser mechanism.

Error Code: 387
Description: Dispenser offline - error validating configuration.
Recommended Action:
Dispenser failed to identify the dispenser type installed. Verify all connectors to the dispenser mechanism. Restart operating system. Clear terminal error code. If error persists, replace the dispenser mechanism.

Error Code: 388
Description: Dispenser offline - NMD require Reject Vault and at least one cassette.
Recommended Action:
Verify that the Reject Vault and one cassette are present in the dispenser mechanism. Clear terminal error code. If error persists, replace the dispenser mechanism.

Error Code: 389
Description: Dispenser offline. Detected offline error check op state.
Recommended Action:
Restart the operating system. Verify the error code lights on the dispenser are operating in proper sequence. Use the NMD test software (available to Triton Certified Service Technicians) and verify the operational error code of the dispenser.

Error Code: 390
Description: Dispenser offline - storing configuration.
Recommended Action: Restart the operating system. Verify the error code lights on the dispenser are operating in proper sequence. Use the NMD test software (avail able to Triton Certified Service Technicians) and verify the operational error code of the dispenser.

Error Code: 391
Description: Dispenser sensor failure.
Recommended Action:
Access the management function diagnostics menus to verify the operational error code of dispenser mechanism sensors. Clean sensors as needed. Replace dispenser components or dispenser if the error persists.

Error Code: 392
Description: Error in last dispense.
Recommended Action:
Check operational error code of dispenser. Replace dispenser if error code persists.

Error Code: 395
Description: Multiple cassette of the same type.
Recommended Action:
NMD dispenser allows for only one of each cassette ID to be installed. Verify each cassette ID. Replace cassette or Inject New Cassette ID.

Error Code: 500
Description: SPED Read Error.
Recommended Action:
Verify all SPED connections. Restart the operating system. Inspect the battery for a voltage reading of greater than 2.8 VCD. Replace SPED battery is below 2.8 VDC. Replace SPED if error persists.

Error Code: 501
Description: SPED invalid return record.
Recommended Action: Refer to error 500.

Error Code: 502
Description: SPED read type error.
Recommended Action:
Refer to error 500.

Error Code: 503
Description: SPED invalid command.
Recommended Action:
Refer to error 500.

Error Code: 504
Description: SPED invalid return ID.
Recommended Action:
Refer to error 500.

Error Code: 505
Description: SPED device busy.
Recommended Action:
Refer to error 500.

Error Code: 506
Description: SPED invalid request.
Recommended Action:
Refer to error 500.

Error Code: 507
Description: SPED sequence error.
Recommended Action:
Refer to error 500.

Error Code: 508
Description: SPED LRC error.
Recommended Action:
Refer to error 500.

Error Code: 509
Description: SPED no data.
Recommended Action:
Refer to error 500.

Error Code: 510
Description: SPED invalid message ID.
Recommended Action:
Refer to error 500.

Error Code: 511
Description: SPED Data overflow.
Recommended Action:
Refer to error 500.

Error Code: 512
Description: SPED device idle.
Recommended Action:
Refer to error 500.

Error Code: 513
Description: SPED device offline.
Recommended Action:
Refer to error 500.

Error Code: 514
Description: SPED device bit stuck.
Recommended Action:
Refer to error 500.

Error Code: 515
Description: SPED device attention stuck.
Recommended Action:
Refer to error 500.

Error Code: 516
Description: SPED device no attention.
Recommended Action:
Refer to error 500.

Error Code: 517
Description: SPED device timeout.
Recommended Action:
Refer to error 500.

Error Code: 518
Description: SPED command sequence error.
Recommended Action:
Refer to error 500.

Error Code: 519
Description: SPED invalid command data.
Recommended Action:
Refer to error 500.

Error Code: 520
Description: SPED device reset.
Recommended Action:
Refer to error 500.

Error Code: 521
Description: SPED clear key
Recommended Action:.
Refer to error 500.

Error Code: 522
Description: EJ error.
Recommended Action:
Inspect electronic journal cabling. Reseat connections. Restart operating system. Replace electronic journal.

Error Code: 523
Description: EJ data size error.
Recommended Action:
Refer to error 522.

Error Code: 524
Description: EJ bad command.
Recommended Action:
Refer to error 522.

Error Code: 525
Description: EJ invalid ID.
Recommended Action:
Refer to error 522.

Error Code: 526
Description: EJ device busy.
Recommended Action:
Refer to error 522.

Error Code: 527
Description: EJ invalid request.
Recommended Action: Refer to error 522.

Error Code: 528
Description: EJ sequence error.
Recommended Action:
Refer to error 522.

Error Code: 529
Description: EJ device offline.
Recommended Action:
Refer to error 522.

Error Code: 530
Description: EJ EXT error.
Recommended Action:
Refer to error 522.

Error Code: 531
Description: EJ SOH error.
Recommended Action:
Refer to error 522.

Error Code: 532
Description: EJ STX error.
Recommended Action:
Refer to error 522.

Error Code: 533
Description: EJ BCC error.
Recommended Action:
Refer to error 522.

Error Code: 534
Description: EJ device reset.
Recommended Action:
Refer to error 522.

Error Code: 535
Description: Card Reader - Data size error.
Recommended Action:
Inspect card reader cabling. Inspect card reader for foreign objects. Clear the terminal error code. If error persists, reboot the ATM. Replace the card reader if error persists.

Error Code: 536
Description: Card Reader - Device read error.
Recommended Action:
Refer to error code 535.


Error Code: 537
Description: Card Reader - Invalid Record.
Recommended Action:
Refer to error code 535.

Error Code: 538
Description: Card Reader - Reader type error.
Recommended Action:
Refer to Error code 535.

Error Code: 539
Description: Card Reader - Invalid track.
Recommended Action:
Refer to error code 535.

Error Code: 540
Description: Card Reader - Invalid message.
Recommended Action:
Refer to error code 535.

Error Code: 541
Description: Card Reader - Com error.
Recommended Action:
Refer to Error/Error code 535.

Error Code: 542
Description: Card Reader - Device busy.
Recommended Action:
Refer to error code 535.

Error Code: 543
Description: Card Reader - Sequence error.
Recommended Action:
Refer to error code 535.

Error Code: 544
Description: Card Reader - Invalid request.
Recommended Action:
Refer to error code 535.

Error Code: 545
Description: Card Reader - LRC error.
Recommended Action:
Refer to error code 535.

Error Code: 546
Description: Card Reader - No data.
Recommended Action:
Refer to error code 535.

Error Code: 547
Description: Card Reader - Start sentinel not found.
Recommended Action: Refer to error code 535.

Error Code: 548
Description: Card Reader - End sentinel not found.
Recommended Action:
Refer to error code 535.

Error Code: 549
Description: Card Reader - Parity error.
Recommended Action:
Refer to error code 535.

Error Code: 550
Description: Card Reader - Card not removed.
Recommended Action:
Refer to error code 535.

Error Code: 551
Description: Card Reader - Card removed to slow.
Recommended Action:
Refer to error code 535.

Error Code: 552
Description: Card Reader - Device received invalid request.
Recommended Action:
Refer to error code 535.

Error Code: 553
Description: Card Reader - device offline.
Recommended Action:
Refer to error code 535.

Error Code: 554
Description: Card Reader - device reset.
Recommended Action:
Refer to error code 535.

Error Code: 555
Description: Card Reader - System timeout.
Recommended Action:
Refer to error code 535.

Error Code: 556
Description: System timeout.
Recommended Action:
An operating system timeout has occurred. Verify operation of the power supply. Restart ATM. If error persists, replace the main board assembly.

Error Code: 557
Description: System device reset.
Recommended Action:
Verify operation of the power supply. Restart ATM. Clear the error. If error persists, replace the main board assembly.

Error Code: 558
Description: System sync error.
Recommended Action:
See error code 557.

Error Code: 559
Description: System error.
Recommended Action:
See error code 557.

Error Code: 560
Description: Unknown device error.
Recommended Action:
See error code 557.

Error Code: 561
Description: Software error.
Recommended Action:
See error code 557.

Error Code: 562
Description: SPED error.
Recommended Action:
Inspect cable from Main Board assembly to the SPED module for damage. Make sure that cable is connected at both ends. Verify that the DC operating voltages are correct. Restart ATM. Clear the error. If error persists, replace the SPED module.

Error Code: 565
Description: Cabinet door open.
Recommended Action:
Close the control panel door. Reset error code code. If error persists, verify the operation of cabinet door switch. Replace as needed.

Error Code: 566
Description: Vault door open.
Recommended Action:
Close vault door. Reset error code. If error persists, check the operation of the vault door switch. Replace as needed.

Error Code: 567
Description: Security module not found.
Recommended Action:
Inspect cable from main board assembly to the security module for damage. Make sure that the cable is connected at both ends. Restart ATM. Clear the error. If error persists, replace the security module.

Error Code: 568
Description: Security module com failed.
Recommended Action:
See error code 567.

Error Code: 569
Description: Security module attached dev com failed.
Recommended Action:
See error code 567.

Error Code: 570
Description: Security module dev port setup.
Recommended Action:
See error code 567.

Error Code: 571
Description: Invalid default transaction.
Recommended Action:
To Be Determined.

Error Code: 572
Description: SPED key from pad cmd aborted by user.
Recommended Action:
Inspect cable from main board assembly to the SPED module for damage. Make sure that the cable is connected at both ends. Restart ATM. Clear the error. If error persists, replace the SPED module.

Error Code: 573
Description: SPED keys from pad cmd verify failed.
Recommended Action:
Inspect cable from Main Board assembly to the SPED module for damage. Make sure that the cable is connected at both ends. Restart ATM. Clear the error. If error persists, replace the SPED module.

Error Code: 574
Description: SNA comms error.
Recommended Action:
To be determined.

Error Code: 575
Description: Timeout waiting to send command to dispenser.
Recommended Action:
Inspect the serial communication cables from the main board assembly to the electronic journal and from the electronic journal to the dispenser for damage. Make sure that each cable is connected securely at both ends. Replace the cable if they appear damaged. Verify the proper DC operating voltages are applied to the dispenser mechanism. Possible defective components include main board assembly, the electronic journal, the serial communications cables, the DC power cables, the power supply, and the dispenser mechanism.

Error Code: 576
Description: Timeout waiting to receive response from dispenser.
Recommended Action:
Inspect the serial communication cables from the main board assembly to the electronic journal and from the electronic journal to the dispenser for damage. Make sure that each cable is connected securely at both ends. Replace the cable if they appear damaged. Verify the proper DC operating voltages are applied to the dispenser mechanism. Possible defective components include main board assembly, the electronic journal, the serial communications cables, the DC power cables, the power supply, and the dispenser mechanism.

Error Code: 577
Description: Card reader disabled.
Recommended Action:
Inspect card reader cable. Inspect the card reader for foreign objects. Replace the cable or clean the card reader as needed. Clear the error. Restart the ATM. If the error persists, replace the card reader.

Error Code: 578
Description: Card reader present timeout.
Recommended Action:
Inspect card reader cable. Inspect the card reader for foreign objects. Replace the cable or clean the card reader as needed. Clear the error. Restart the ATM. If the error persists, replace the card reader.

Error Code: 579
Description: SPED - Enable keypad command failed.
Recommended Action:
Inspect cable from Main Board assembly to the SPED Module for damage. Make sure that the cable is connected at both ends. Verify that the DC operating voltages are correct. Restart ATM. Clear the error. If error persists, replace the SPED module.

Error Code: 580
Description: SPED - Disable keypad command failed.
Recommended Action:
Inspect cable from main board assembly to the SPED module for damage. Make sure that the cable is connected at both ends. Verify that the DC operating voltages are correct. Restart ATM. Clear the error. If error persists, replace the SPED module.

Error Code: 581
Description: SPED - Enable key from pad module failed.
Recommended Action:
Inspect cable from main board assembly to the SPED module for damage. Make sure that the cable is connected at both ends. Verify that the DC operating voltages are correct. Restart ATM. Clear the error. If error persists, replace the SPED module.

Error Code: 582
Description: SPED - Disable key from pad module.
Recommended Action:
Inspect cable from main board assembly to the SPED module for damage. Make sure that the cable is connected at both ends. Verify that the DC operating voltages are correct. Restart ATM. Clear the error. If error persists, replace the SPED module.

Error Code: 583
Description: SPED - Enable PIN entry mode failed.
Recommended Action:
Inspect cable from main board assembly to the SPED module for damage. Make sure that the cable is connected at both ends. Verify that the DC operating voltages are correct. Restart ATM. Clear the error. If error persists, replace the SPED module.

Error Code: 584
Description: SPED - Disable PIN entry mode failed.
Recommended Action:
Inspect cable from main board assembly to the SPED module for damage. Make sure that the cable is connected at both ends. Verify that the DC operating voltages are correct. Restart ATM. Clear the error. If error persists, replace the SPED module.

Error Code: 585
Description: SPED - Enable JETCO PIN entry mode failed.
Recommended Action:
Inspect cable from main board assembly to the SPED module for damage. Make sure that the cable is connected at both ends. Verify that the DC operating voltages are correct. Restart ATM. Clear the error. If error persists, replace the SPED module.

Error Code: 586
Description: SPED - Enable JETCO PIN entry mode failed.
Recommended Action:
Inspect cable from main board assembly to the SPED module for damage. Make sure that the cable is connected at both ends. Verify that the DC operating voltages are correct. Restart ATM. Clear the error. If error persists, replace the SPED module.

Error Code: 586
Description: SPED - Enable JETCO PIN entry mode failed.
Recommended Action:
Inspect cable from main board assembly to the SPED module for damage. Make sure that the cable is connected at both ends. Verify that the DC operating voltages are correct. Restart ATM. Clear the error. If error persists, replace the SPED module.


Error Code: 588
Description: ERR_PRESENTER_OFFLINE
Recommended Action:
Verify that a cable from the docking board to the presenter controller board is securely connected at both ends. If the cable appears undamaged, and it is securely connected at the docking board and the presenter controller board, Replace the presenter assembly. If replacing the presenter does not clear the error, other possible causes of this problem may be the main board assembly or the docking board.

Error Code: 589
Description: ERR_PRESENTER_MOTOR_STALLED
Recommended Action:
Inspect the gears assembly on the presenter for possible damage. Replace the presenter if gear damage is apparent. Open printer and inspect the presenter paper path for jammed paper. Remove any jammed paper or other debris.


Error Code: 590
Description: ERR_PRESENTER_EXIT_JAM
Recommended Action:
Open printer and inspect the presenter paper path for jammed paper. Remove any jammed paper or other debris. Restart the cash dispenser. If the error persist, replace the presenter module.


Error Code: 591
Description: ERR_PRESENTER PAPER_NOT_DETECTED
Recommended Action:
Open the printer and verify that the paper is not jamming in the printer between the printer output and the input to the cutter. Clear all debris from the printer path. Restart the ATM. If the paper continues to jam, it may be necessary to replace the cutter or printer. If replacing the printer of cutter does not clear the error, replace the presenter module.

Error Code: 592
Description:ERR_SPED_DEVICE_REPORTED_COMMAND_ FAILED
Recommended Action:
Inspect cable from main board assembly to the SPED module for damage. Make sure that the cable is connected at both ends. Verify that the DC operating voltages are correct. Restart ATM. Clear the error. If error persists, replace the SPED module.

Error Code: 593
Description: ERR_SPED_IN_USE
Recommended Action:
Inspect cable from main board assembly to the SPED module for damage. Make sure that the cable is connected at both ends. Verify that the DC operating voltages are correct. Restart ATM. Clear the error. If error persists, replace the SPED module.

Error Code: 594
Description: ERR_SPED_DEVICE _REPORTED_COMM_ERROR
Recommended Action:
Inspect cable from main board assembly to the SPED module for damage. Make sure that the cable is connected at both ends. Verify that the DC operating voltages are correct. Restart ATM. Clear the error. If error persists, replace the SPED module.

Error Code: 595
Description: ERR_SPED_RETURNED_INVALID_AMOUNT_OF_DATA
Recommended Action:
Inspect cable from main board assembly to the SPED module for damage. Make sure that the cable is connected at both ends. Verify that the DC operating voltages are correct. Restart ATM. Clear the error. If error persists, replace the SPED module.

Error Code: 596
Description: ERR_SPED_INVALID _SPED_TYPE
Recommended Action:
Inspect cable from main board assembly to the SPED module for damage. Make sure that the cable is connected at both ends. Verify that the DC operating voltages are correct. Restart ATM. Clear the error. If error persists, replace the SPED module.

Error Code: 597
Description: ERR_SPED_INVALID_SPED_COMMS_PROTOCOL
Recommended Action:
Inspect cable from main board assembly to the SPED module for damage. Make sure that the cable is connected at both ends. Verify that the DC operating voltages are correct. Restart ATM. Clear the error. If error persists, replace the SPED module.

Error Code: 598
Description: ERR_SPED_INVALID_DEVICE_CLASS
Recommended Action:
Inspect cable from main board assembly to the SPED module for damage. Make sure that the cable is connected at both ends. Verify that the DC operating voltages are correct. Restart ATM. Clear the error. If error persists, replace the SPED module.

Error Code: 599
Description: ERR_SPED_REPORTED_UNRECOGNIZED_COMMAND
Recommended Action:
Inspect cable from main board assembly to the SPED module for damage. Make sure that the cable is connected at both ends. Verify that the DC operating voltages are correct. Restart ATM. Clear the error. If error persists, replace the SPED module.

Error Code: 600
Description: ERR_SPED_REPORTED_BLOCK_DOES_NOT_EXIST
Recommended Action:
Inspect cable from main board assembly to the SPED module for damage. Make sure that the cable is connected at both ends. Verify that the DC operating voltages are correct. Restart ATM. Clear the error. If error persists, replace the SPED module.

Error Code: 601
Description: ERR_SPED_REPORTED_INVALID_ENCRYPT_MODE
Recommended Action:
Inspect cable from main board assembly to the SPED module for damage. Make sure that the cable is connected at both ends. Verify that the DC operating voltages are correct. Restart ATM. Clear the error. If error persists, replace the SPED module.

Error Code: 602
Description: ERR_SPED_REPORTED_UNSUPPORTED_CLEAR_OPTION
Recommended Action:
Inspect cable from main board assembly to the SPED module for damage. Make sure that the cable is connected at both ends. Verify that the DC operating voltages are correct. Restart ATM. Clear the error. If error persists, replace the SPED module.

Error Code: 603
Description: ERR_SPED_REPORTED_TAMPER_PRESENT
Recommended Action:
Inspect cable from main board assembly to the SPED module for damage. Make sure that the cable is connected at both ends. Verify that the DC operating voltages are correct. Restart ATM. Clear the error. If error persists, replace the SPED module.

Error Code: 604
Description: ERR_SPED_REPORTED_INVALID_KEY_INDEX
Recommended Action:
Inspect cable from main board assembly to the SPED module for damage. Make sure that the cable is connected at both ends. Verify that the DC operating voltages are correct. Restart ATM. Clear the error. If error persists, replace the SPED module.

Error Code: 605
Description: ERR_SPED_REPORTED_PARENT_KEY_NOT_LOADED
Recommended Action:
Inspect cable from main board assembly to the SPED module for damage. Make sure that the cable is connected at both ends. Verify that the DC operating voltages are correct. Restart ATM. Clear the error. If error persists, replace the SPED module.

Error Code: 606
Description: ERR_SPED_REPORTED_WRONG_DATA_LENGTH
Recommended Action:
Inspect cable from main board assembly to the SPED module for damage. Make sure that the cable is connected at both ends. Verify that the DC operating voltages are correct. Restart ATM. Clear the error. If error persists, replace the SPED module.

Error Code: 607
Description: ERR_SPED_REPORTED_PIN_RETRY_TOO_SOON
Recommended Action:
Inspect cable from main board assembly to the SPED module for damage. Make sure that the cable is connected at both ends. Verify that the DC operating voltages are correct. Restart ATM. Clear the error. If error persists, replace the SPED module.

Error Code: 608
Description: ERR_SPED_SELFTEST_CRC_FAILED
Recommended Action:
Inspect cable from main board assembly to the SPED module for damage. Make sure that the cable is connected at both ends. Verify that the DC operating voltages are correct. Restart ATM. Clear the error. If error persists, replace the SPED module.

Error Code: 609
Description: ERR_SPED_SELFTEST_CRYPTOGRAPHIC_ERROR
Recommended Action:
Inspect cable from main board assembly to the SPED module for damage. Make sure that the cable is connected at both ends. Verify that the DC operating voltages are correct. Restart ATM. Clear the error. If error persists, replace the SPED module.

Error Code: 610
Description: ERR_SPED_SELFTEST_BATTERY_LOW_STATUS
Recommended Action:
Inspect cable from main board assembly to the SPED module for damage. Make sure that the cable is connected at both ends. Verify that the DC operating voltages are correct. Restart ATM. Clear the error. If error persists, replace the SPED module.

Error Code: 611
Description: ERR_SPED_SELFTEST_SERIAL_NUMBER_ERROR
Recommended Action:
Inspect cable from main board assembly to the SPED module for damage. Make sure that the cable is connected at both ends. Verify that the DC operating voltages are correct. Restart ATM. Clear the error. If error persists, replace the SPED module.

Error Code: 612
Description: ERR_SPED_TAMPER_STATUS_COLD
Recommended Action:
Inspect cable from main board assembly to the SPED module for damage. Make sure that the cable is connected at both ends. Verify that the DC operating voltages are correct. Restart ATM. Clear the error. If error persists, replace the SPED module.

Error Code: 613
Description: ERR_SPED_TAMPER_STATUS_FRONT
Recommended Action:
Inspect cable from main board assembly to the SPED module for damage. Make sure that the cable is connected at both ends. Verify that the DC operating voltages are correct. Restart ATM. Clear the error. If error persists, replace the SPED module.

Error Code: 614
Description: ERR_SPED_TAMPER_STATUS_BACK
Recommended Action:
Inspect cable from main board assembly to the SPED module for damage. Make sure that the cable is connected at both ends. Verify that the DC operating voltages are correct. Restart ATM. Clear the error. If error persists, replace the SPED module.

Error Code: 615
Description: ERR_SPED_TAMPER_STATUS_GRID
Recommended Action:
Inspect cable from main board assembly to the SPED module for damage. Make sure that the cable is connected at both ends. Verify that the DC operating voltages are correct. Restart ATM. Clear the error. If error persists, replace the SPED module.

Error Code: 616
Description: ERR_SPED_TAMPER_STATUS_VOLTAGE
Recommended Action:
Inspect cable from main board assembly to the SPED module for damage. Make sure that the cable is connected at both ends. Verify that the DC operating voltages are correct. Restart ATM. Clear the error. If error persists, replace the SPED module.

Error Code: 617
Description: ERR_SPED_SERIAL_NUMBER_CHANGE
Recommended Action: Inspect cable from main board assembly to the SPED module for damage. Make sure that the cable is connected at both ends. Verify that the DC operating voltages are correct. Restart ATM. Clear the error. If error persists, replace the SPED module.



Tranax Error Codes

Error Code: 00000
Desription: Normal Status
Resoution: Normal Status

Error Code: 20001
Desription: Unable to detect a cassette
Resoution: Remove and replace cassette - Check the micro-switch located on the inside left wall of the dispenser. Adjust the micro-switch if needed, also check the white plastic clips that hold the cassette in place. If they are broken the cassette will not stay in the dispenser.

Error Code: 20002
Desription: Low Cash
Resoution: Low cash warning sensor on dispenser is open. When "Low Cash Warning" is enabled in the Transaction Setup menu, this sensor will open when the cassette reaches (+/-) 75 bills. If this machine is typically stocked with a low amount of bills, we recommend disabling this function.

Error Code: 20003
Desription: Reject Bin is Full
Resoution: Empty reject bin - if bin is empty, do a Cassette Total (from the settlement menu) - If that doesn't help then check that AP, BIOS and CDU ROM versions are compatible.

Error Code: 20004
Desription: Vault Door is Open
Resoution: This error occurs when the circuit between the mainboard and the door switch is open. Check vault door switch. This white plunger switch is located in the upper left corner of the vault, or on along the front edge of the cash dispenser tray. Also check that black and white, 2 wire connector is properly connected at rear of main board. Move the vault switch forward to aid door clearance problems. Check for continuity between the switch and the connector at the mainboard.

Error Code: 20005
Desription: CDU Type Mismatch
Resoution: CDU ROM does not match AP software. The dispenser and mainboard are programmed with a country code (USA or Canada). The two codes must match. If they do not the 20005 error will occur in which case the CDU will need to be reprogrammed to match the AP on the mainboard. Also, if the wrong parameters are entered when the CDU is programmed, this error can occur.

Error Code: 20010
Desription: Receipt Paper Jam
Resoution: Remove jammed paper - Release receipt paper drawer by pressing the tab with the green sticker located at the front of the printer. In most cases you may have to remove the printer to locate difficult jams. NOTE: Do NOT use metal objects to clear jams, use a business card or stiff paper. Make sure you only are using 21# paper. Paper of a lesser thickness is more prone to jamming.

Error Code: 20012
Desription: Receipt printer feed lever open
Resoution: Close the feed tray on the printer. If the paper tray is already closed, try opening and closing the tray, try the printer reset switch. Otherwise the printer may require service.

Error Code: 20013
Desription: Receipt paper is empty
Resoution: Replenish the paper roll, if there is already paper in the printer look for jams or obstructions. Try the printer reset switch. If it still has the error the printer may require service.

Error Code: 20014
Desription: Thermal printer is overheated
Resoution: If this error occurs during the printing of a long journal, then allow the printer to cool and try again. You may also want to try the reset button on the printer to clear this error. If this error persists, the printer will require service.

Error Code: 20215
Desription: CDU detects bills prior to dispensing
Resoution: This means that while the ATM was initializing it detected a blocked sensor in the cash dispenser (CS2 sensor). Remove any jammed bills from the dispenser, if no bills are present try using compressed air to clean the dispenser (a sensor may be blocked by dust). Check and reseat all belts. Loose belts can slip off rollers and block sensors.

Error Code: 21315
Desription: CDU detects bills prior to dispensing
Resoution: This means that while the ATM was initializing it detected a blocked sensor in the cash dispenser (CS13 sensor). Remove any jammed bills from the dispenser, if no bills are present try using compressed air to clean the dispenser (a sensor may be blocked by dust). Check and reseat all belts. Loose belts can slip off rollers and block sensors.

Error Code: 21A15
Desription: CDU detects bills prior to dispensing
Resoution: This means that while the ATM was initializing it detected a blocked sensor in the cash dispenser (CS1A sensor). Remove any jammed bills from the dispenser, if no bills are present try using compressed air to clean the dispenser (a sensor may be blocked by dust). Check and reseat all belts. Loose belts can slip off rollers and block sensors.

Error Code: 21B15
Desription: CDU detects bills prior to dispensing
Resoution: This means that while the ATM was initializing it detected a blocked sensor in the cash dispenser (CS1B sensor). Remove any jammed bills from the dispenser, if no bills are present try using compressed air to clean the dispenser (a sensor may be blocked by dust). Check and reseat all belts. Loose belts can slip off rollers and block sensors.

Error Code: 24A15
Desription: CDU detects bills prior to dispensing
Resoution: This means that while the ATM was initializing it detected a blocked sensor in the cash dispenser (CS4A sensor). Remove any jammed bills from the dispenser, if no bills are present try using compressed air to clean the dispenser (a sensor may be blocked by dust). Check and reseat all belts. Loose belts can slip off rollers and block sensors.

Error Code: 24B15
Desription: CDU detects bills prior to dispensing
Resoution: This means that while the ATM was initializing it detected a blocked sensor in the cash dispenser (CS4B sensor). Remove any jammed bills from the dispenser, if no bills are present try using compressed air to clean the dispenser (a sensor may be blocked by dust). Check and reseat all belts. Loose belts can slip off rollers and block sensors.

Error Code: 90001
Desription: Error during card swipe
Resoution: This error occurs when customer attempts to swipe their card and are unsuccessful. It may indicate that the card reader needs to be cleaned, repositioned or simply that the customer didn't swipe their card properly. If persistent, clean and test the card reader in diagnostics. NOTE: it is very common to see this error in the error summary and does not usually indicate a bad or defective part.

Error Code: A0008
Desription: Receipt paper cutter error
Resoution: Remove any jammed paper. You may need to remove the printer to clear jams. NOTE: Do not use metal objects to clear the jam. Use a business card or stiff paper to clear jams. Otherwise try the reset button or have the printer serviced.

Error Code: A0803
Desription: Receipt Paper Jam
Resoution: Remove jammed paper - Release receipt paper drawer by pressing the tab with the green sticker located at the front of the printer. You may need to remove the printer from the ATM to access the jam. NOTE: Do not use metal objects to clear jams, use a business card or stiff paper to poke around.

Error Code: A0808
Desription: Receipt paper cutter error
Resoution: Remove any jammed paper. You may need to remove the printer to clear jams. NOTE: Do not use metal objects to clear the jam. Use a business card or stiff paper to clear jams. Otherwise try the reset button or have the printer serviced.

Error Code: ADN04
Desription: Printer connection error
Resoution: Check cables between Printer and Mainboard, remove cables (even though they may be attached) and re-connect. Use an electrical parts contact cleaner to clean the terminals. Try the reset button on the printer. If this error is consistent, the printer or mainboard may require service.

Error Code: ADN0F
Desription: Printer connection error
Resoution: Check cables between Printer and Mainboard, remove cables (even though they may be attached) and re-connect. Use an electrical parts contact cleaner to clean the terminals. Try the reset button on the printer. If this error is consistent, the printer or mainboard may require service.

Error Code: ADNxx
Desription: Printer connection error
Resoution: Check cables between Printer and Mainboard, remove cables (even though they may be attached) and re-connect. Use an electrical parts contact cleaner to clean the terminals. Try the reset button on the printer. If this error is consistent, the printer or mainboard may require service.

Error Code: Axxx2
Desription: Thermal printer is overheated - during operation
Resoution: If this error occurs during the printing of a long journal, then allow the printer to cool and try again. You may also want to try the reset button on the printer to clear this error. If this error persists, the printer will require service.

Error Code: Axxx3
Desription: Receipt Paper Jam
Resoution: Remove jammed paper - Release receipt paper drawer by pressing the tab with the green sticker located at the front of the printer. You may need to remove the printer from the ATM to access the jam. NOTE: Do NOT use metal objects to clear jams, use a business card or stiff paper to poke around.

Error Code: Axxx4
Desription: Receipt paper is empty
Resoution: Replenish the paper roll. If roll is ok, then try the reset button on the printer. Otherwise the printer needs service.

Error Code: Axxx5
Desription: Receipt paper is jamming during loading
Resoution: Remove any jammed paper and then reload. You may need to remove the printer to clear jams. NOTE: Do not use metal objects to clear the jam. Use a business card or stiff paper to clear jams. Otherwise try the reset button or have the printer serviced.

Error Code: C0011
Desription: CDU sensor is tripped
Resoution: This indicates that during a dispense, the sensor located at the front of the CDU shows a blockage (CS13 or CS2). The primary reason for this is a bill which bounces back from the cash tray (sometimes from a customers fingers). Check the front of the CDU and the cash tray for blockage. Reinitialize the ATM to put back in service. In the case of a dispute from the error, use CDU data in the journal to verify how many notes were actually dispensed.

Error Code: C0014
Desription: CDU sensor is tripped
Resoution: Similar to the COO11 error, this would indicate a bill jam close to the exit of the CDU or near the reject bin. Check for jammed notes or blocked sensors.

Error Code: C001x
Desription: CDU sensor is tripped
Resoution: Most typically a COO11 error, this would indicate a bill jam at the exit sensor of the Cash Dispenser. Usually caused by a customer putting fingers in the cash drawer during dispense. Other than upgrading the cash tray or using a sign to warn customers, you can loosen the screws that hold the dispenser and slide it back.

Error Code: C0028
Desription: CDU sensor is tripped
Resoution: Check dispenser for jammed bills and restart the machine. If no bills are present try using compressed air to clean the dispenser (a sensor may be blocked by dust). Otherwise the dispenser may require service.

Error Code: C002x
Desription: CDU sensor is tripped
Resoution: Check dispenser for jammed bills and restart the machine. If no bills are present try using compressed air to clean the dispenser (a sensor may be blocked by dust). Otherwise the dispenser may require service

Error Code: C0030
Desription: CDU motor failure
Resoution: Motor speed (measured at the encoder wheel) was not within spec. Verify that CS8 or encoder wheel sensor is in place and wire connection is good. Can indicate a bad motor or encoder sensor.

Error Code: C0031
Desription: CDU Gate solenoid error
Resoution: The CDU did not respond to its solenoid function check. Check the wiring connections to the solenoid(s). Check wiring connections to the CDU main board.

Error Code: C0032
Desription: Outlet solenoid error
Resoution: Check and verify all connections to the dispenser circuit board. Check wiring to the solenoid(s).

Error Code: C0033
Desription: CDU Encoder error
Resoution: Usually caused by loss of battery power to the CDU mainboard. The only way to recover from this error is to reprogram the CDU data. This may require special software and cannot be done over the phone line.

Error Code: C0034
Desription: Double Note detect module failure
Resoution: Double detect module reporting error, check wiring to the module.

Error Code: C0035
Desription: Double Note detect module failure (2)
Resoution: Double detect module reporting error, check wiring to the module.

Error Code: C0036
Desription: Detected notes in path before initializing
Resoution: One or more sensors in the dispenser detected a blockage prior to initializing. Check for notes in the Cash Dispenser. If no bills are present try using compressed air to clean the dispenser (a sensor may be blocked by dust). Otherwise the dispenser may require service.

Error Code: C0039
Desription: Gate sensor open during initializing
Resoution: Check the sensor that is activated when you close the reject bin door (2k/4k dispensers only). If the sensor is not being pressed then the error will occur. Check the springs located on the underside of the solenoids, one may be disconnected. Otherwise the CDU will require repair / replacement.

Error Code: C003B
Desription: Notes detected during installation
Resoution: Check for notes in the Cash Dispenser. If no bills are present try using compressed air to clean the dispenser (a sensor may be blocked by dust). Otherwise the dispenser may require service.

Error Code: C0040
Desription: Cassette removed during dispense
Resoution: Reset the cassette, check position of microswitch on right rear wall of cassette bay in the dispenser. Check the condition of the white plastic cassette retaining clips in the dispenser.

Error Code: C0041
Desription: Tried to dispense notes more than 5 times
Resoution: Check the condition of the cash in the cassette. Verify that the cash is of good quality. The CDU belts or the Cassette rollers may need to be cleaned (rubbing alcohol). Check that the denomination in Transaction setup matches the actual denomination loaded.

Error Code: C0042
Desription: Note jam
Resoution: Check for notes in the Cash Dispenser. If no bills are present try using compressed air to clean the dispenser (a sensor may be blocked by dust). Otherwise the dispenser may require service.

Error Code: C0043
Desription: More than 10 notes rejected during one transaction
Resoution: Verify the quality of the cash. Straighten and shuffle cash in the cassette. Check the reject analysis to determine the cause of reject (reports menu). If the cash is of known good quality then try cleaning the cassette and dispenser. Otherwise service to cassette or dispenser may be required.

Error Code: C0044
Desription: More than 5 notes rejected consecutively
Resoution: Verify the quality of the cash. Straighten and shuffle cash in the cassette. Check the reject analysis to determine the cause of reject (reports menu). If the cash is of known good quality then try cleaning the cassette and dispenser. Otherwise service to cassette or dispenser may be required.

Error Code: C0046
Desription: CDU Hardware Failure
Resoution: Error reported during CDU initialization. Check cabling and potential blockages and power cycle ATM.

Error Code: C0047
Desription: Feed error
Resoution: This error occurs when the dispenser attempts to pull a bill from the cassette and is unsucessfull before the dispenser times out. Depending on the model of dispenser there are different causes and possible solutions. It can be as simple as the cassette being empty, rollers need cleaning to a firmware upgrade to the CDU.

Error Code: C0048
Desription: Incorrect bill count
Resoution: Verify cash count in the Settlement menu.

Error Code: C004A
Desription: Jammed notes
Resoution: Check for notes in the Cash Dispenser. If no bills are present try using compressed air to clean the dispenser (a sensor may be blocked by dust). Otherwise the dispenser may require service.

Error Code: C004B
Desription: Long note detected 3 times consecutively
Resoution: Verify the quality of the cash. Straighten and shuffle cash in the cassette. Try cleaning the cassette and dispenser. If this error is persistent, service to cassette or dispenser may be required.

Error Code: C004C
Desription: Miscount of notes between sensors
Resoution: Verify operation of exit gate. Check the number of dispensed notes. Clean the dispenser and test using diagnostics. Dispenser may require service.

Error Code: C004D
Desription: Cash cassette not properly set
Resoution: Reset the cassette, check position of microswitch on right rear wall of cassette bay in the dispenser. Check the condition of the white plastic cassette retaining clips in the dispenser. MB1000 check condition of the clutch alignment screw.

Error Code: C004E
Desription: Miscount of notes between sensors
Resoution: Test CDU using diagnostics, use journal to verify amount of dispensed notes versus requested notes. Clean dispenser and cassette. If error is persistent the dispenser may require service.

Error Code: C004F
Desription: Miscount of notes between sensors
Resoution: Test CDU using diagnostics, use journal to verify amount of dispensed notes versus requested notes. Clean dispenser and cassette. If error is persistent the dispenser may require service.

Error Code: C0050
Desription: Power failure during dispense
Resoution: Remove any notes from path. Before reinitializing the ATM, first the verify amount of dispensed notes in the cassette against the journal.

Error Code: C0051
Desription: Over 150 notes requested
Resoution: Possibly due to too many rejects, may require repair or cleaning if consistent. Check the Reject Analysis, this may help determine the cause. Cash quality, condition of the rollers in the cassette can effect this condition.

Error Code: C0052
Desription: Detected notes in path after dispense
Resoution: Remove any notes from path, verify amount of dispensed notes. Clean dispenser. Verify the amount of bills against the journal.

Error Code: C0053
Desription: CDU double detect module failure.
Resoution: Double detect module may require adjustment. Check wiring and CDU mainboard connections.

Error Code: C0055
Desription: Detected long notes at outlet sensor
Resoution: (See definition of C0011 error) this is typically a bounce back of a bill during dispense causing the exit sensor to remain blocked for a longer time than is expected.

Error Code: C0056
Desription: Exit gate sensor failure
Resoution: Check condition of exit gate, and the exit gate sensor.

Error Code: C0057
Desription: Cassette information is not properly set
Resoution: CDU programming is not accurate or complete.

Error Code: C0059
Desription: Cash cassette 2 removed prior to dispense.
Resoution: Set the cash cassette. Inspect the cassette detection microswitch. Reposition the microswitch if necessary.

Error Code: C005A
Desription: Cash cassette 1 removed prior to dispense
Resoution: Set the cash cassette. Inspect the cassette detection microswitch. Reposition the microswitch if necessary.

Error Code: C005B
Desription: Cash cassette 2 misfeed
Resoution: Check cassette for jams, check condition of bills in cassette.

Error Code: C005D
Desription: Double detect constantly
Resoution: Inspect double detect module and adjust as necessary. Check and clean the cassette and rollers, verify the quality of cash.

Error Code: C005E
Desription: Dispense command size check error
Resoution: Re-initialize machine, verify connections to mainboard. Check for unplugged sensors.

Error Code: C005F
Desription: Dispense command error
Resoution: Re-initialize machine, verify connections, check for unplugged sensors.

Error Code: C006x
Desription: Sensor failure
Resoution: Check for notes in the Cash Dispenser. If no bills are present try using compressed air to clean the dispenser (a sensor may be blocked by dust). Otherwise the dispenser may require service.

Error Code: C007x
Desription: Sensor failure
Resoution: Check for notes in the Cash Dispenser. If no bills are present try using compressed air to clean the dispenser (a sensor may be blocked by dust). Otherwise the dispenser may require service.

Error Code: C0082
Desription: Shutter failure
Resoution: Check all wiring connections to CDU mainboard. Reinitialize CDU.

Error Code: C0083
Desription: Stacker sensor failure
Resoution: Check all wiring connections to CDU mainboard. Reinitialize CDU.

Error Code: C0084
Desription: Shutter close error
Resoution: Check all wiring connections to CDU mainboard. Reinitialize CDU.

Error Code: C00AB
Desription: Notes detected before initalizing
Resoution: Clear notes from dispenser. Possibly dust or foreign object blocking sensor.

Error Code: C00E0
Desription: NS2A, NS2B dark
Resoution: Nanocash only - verify connections to sensors. Check wiring to mainboard.

Error Code: C00E1
Desription: NS4 dark
Resoution: Verify connections to NS4 sensor. Check all wiring to mainboard.

Error Code: CANCE
Desription: User canceled transaction at surcharge
Resoution: This is not an error, but rather a statistic to notify how many users respond "no" to the surcharge notification.

Error Code: CDN05
Desription: CDU connection failure
Resoution: Check cables between CDU and Mainboard, remove cables (even though they may be attached) and re-connect. Use an electrical parts contact cleaner on terminals. This error is of concern only if it is repeated. Outside interference may cause it (neon signs, lights).

Error Code: CDN0F
Desription: CDU connection failure
Resoution: Check cables between CDU and Mainboard, remove cables (even though they may be attached) and re-connect. Use an electrical parts contact cleaner on terminals. This error is of concern only if it is repeated. Outside interference may cause it (neon signs, lights).

Error Code: CDNxx
Desription: CDU connection failure
Resoution: Check cables between CDU and Mainboard, remove cables (even though they may be attached) and re-connect. Use an electrical parts contact cleaner on terminals. This error is of concern only if it is repeated. Outside interference may cause it (neon signs, lights).

Error Code: D0001
Desription: Modem initialization error
Resoution: Check modem in diagnostics or modem test. If persistent, it could be a defective modem. Note: If the modem is defective, this error will most likely occur frequently. One or two instances of this error does not usually indicate a defective part.

Error Code: D0002
Desription: Reversal transaction failed.
Resoution: The ATM attempted to do a reversal and could not. Check transaction with the processor. Verify CDU functionality with diagnostics. Verify phone connection. Look in error summary for D1800, D2000.

Error Code: D0005
Desription: Undefined network processing error
Resoution: Code reported by host processor. Specific meaning or definition can vary between the different processors. Contact your ISO or processor if you encounter an excessive amount of these errors, or you cannot complete a test transaction because of this error.

Error Code: D0011
Desription: Format error in the message.
Resoution: Code reported by host processor. Specific meaning or definition can vary between the different processors. Contact your ISO or processor if you encounter an excessive amount of these errors, or you cannot complete a test transaction because of this error.

Error Code: D0012
Desription: Invalid Transaction
Resoution: Code reported by host processor. Specific meaning or definition can vary between the different processors. Contact your ISO or processor if you encounter an excessive amount of these errors, or you cannot complete a test transaction because of this error.

Error Code: D0013
Desription: Invalid Amount
Resoution: Code reported by host processor. Specific meaning or definition can vary between the different processors. Contact your ISO or processor if you encounter an excessive amount of these errors, or you cannot complete a test transaction because of this error.

Error Code: D0014
Desription: Invalid Card Number
Resoution: Code reported by host processor. Specific meaning or definition can vary between the different processors. Contact your ISO or processor if you encounter an excessive amount of these errors, or you cannot complete a test transaction because of this error.

Error Code: D0019
Desription: Reenter the entire transaction
Resoution: Code reported by host processor (Shazam). Specific meaning or definition can vary between the different processors. Contact your ISO or processor if you encounter an excessive amount of these errors, or you cannot complete a test transaction because of this error.

Error Code: D0020
Desription: Surcharge screen should have been displayed
Resoution: Code reported by host processor. Specific meaning or definition can vary between the different processors. Contact your ISO or processor if you encounter an excessive amount of these errors, or you cannot complete a test transaction because of this error.

Error Code: D0024
Desription: Exceeds issuer withdrawal limit
Resoution: Code reported by host processor. Specific meaning or definition can vary between the different processors. Contact your ISO or processor if you encounter an excessive amount of these errors, or you cannot complete a test transaction because of this error.

Error Code: D0031
Desription: Issuer financial institution is not supported by a processor
Resoution: Code reported by host processor (Shazam). Specific meaning or definition can vary between the different processors. Contact your ISO or processor if you encounter an excessive amount of these errors, or you cannot complete a test transaction because of this error.

Error Code: D0039
Desription: No credit account
Resoution: Code reported by host processor. Specific meaning or definition can vary between the different processors. Contact your ISO or processor if you encounter an excessive amount of these errors, or you cannot complete a test transaction because of this error.

Error Code: D0041
Desription: No credit account found for the CCN
Resoution: Code reported by host processor (Shazam). Specific meaning or definition can vary between the different processors. Contact your ISO or processor if you encounter an excessive amount of these errors, or you cannot complete a test transaction because of this error.

Error Code: D0043
Desription: Stolen Card
Resoution: Code reported by host processor (Shazam). Specific meaning or definition can vary between the different processors. Contact your ISO or processor if you encounter an excessive amount of these errors, or you cannot complete a test transaction because of this error.

Error Code: D0050
Desription: Transaction is not approved
Resoution: Code reported by host processor (Shazam). Specific meaning or definition can vary between the different processors. Contact your ISO or processor if you encounter an excessive amount of these errors, or you cannot complete a test transaction because of this error.

Error Code: D0051
Desription: Insufficient funds
Resoution: Code reported by host processor. Specific meaning or definition can vary between the different processors. Contact your ISO or processor if you encounter an excessive amount of these errors, or you cannot complete a test transaction because of this error.

Error Code: D0052
Desription: No checking account
Resoution: Code reported by host processor. Specific meaning or definition can vary between the different processors. Contact your ISO or processor if you encounter an excessive amount of these errors, or you cannot complete a test transaction because of this error.

Error Code: D0053
Desription: No savings account
Resoution: Code reported by host processor. Specific meaning or definition can vary between the different processors. Contact your ISO or processor if you encounter an excessive amount of these errors, or you cannot complete a test transaction because of this error.

Error Code: D0054
Desription: Expired Card
Resoution: Code reported by host processor. Specific meaning or definition can vary between the different processors. Contact your ISO or processor if you encounter an excessive amount of these errors, or you cannot complete a test transaction because of this error.

Error Code: D0055
Desription: Invalid PIN
Resoution: Code reported from host processor - Verify all programming. In the case of a new installation, if master keys are not bound properly, Terminal ID is not active or if programming is not correct for the host this can occur. If all programming appears correct, contact the processor and have them trace the Terminal ID.

Error Code: D0056
Desription: No card record found
Resoution: Code reported by host processor (Shazam). Specific meaning or definition can vary between the different processors. Contact your ISO or processor if you encounter an excessive amount of these errors, or you cannot complete a test transaction because of this error.

Error Code: D0057
Desription: Transaction not permitted - card
Resoution: Code reported by host processor. Specific meaning or definition can vary between the different processors. Contact your ISO or processor if you encounter an excessive amount of these errors, or you cannot complete a test transaction because of this error.

Error Code: D0058
Desription: Transaction not permitted - Terminal
Resoution: Code reported by host processor. Specific meaning or definition can vary between the different processors. Contact your ISO or processor if you encounter an excessive amount of these errors, or you cannot complete a test transaction because of this error.

Error Code: D0059
Desription: Customer should contact his or her financial institution
Resoution: Code reported by host processor (Shazam). Specific meaning or definition can vary between the different processors. Contact your ISO or processor if you encounter an excessive amount of these errors, or you cannot complete a test transaction because of this error.

Error Code: D0060
Desription: Allowable withdrawal limit is exceeded
Resoution: Code reported by host processor. Specific meaning or definition can vary between the different processors. Contact your ISO or processor if you encounter an excessive amount of these errors, or you cannot complete a test transaction because of this error.

Error Code: D0061
Desription: Exceeded withdrawal limit
Resoution: Code reported by host processor. Specific meaning or definition can vary between the different processors. Contact your ISO or processor if you encounter an excessive amount of these errors, or you cannot complete a test transaction because of this error.

Error Code: D0065
Desription: Exceeds withdrawal frequency limit
Resoution: Code reported by host processor. Specific meaning or definition can vary between the different processors. Contact your ISO or processor if you encounter an excessive amount of these errors, or you cannot complete a test transaction because of this error.

Error Code: D0067
Desription: Capture card at the terminal (requires card be picked up at ATM only).
Resoution: Code reported by host processor (Shazam). Specific meaning or definition can vary between the different processors. Contact your ISO or processor if you encounter an excessive amount of these errors, or you cannot complete a test transaction because of this error.

Error Code: D0075
Desription: Number of PIN tries exceeded
Resoution: Code reported by host processor. Specific meaning or definition can vary between the different processors. Contact your ISO or processor if you encounter an excessive amount of these errors, or you cannot complete a test transaction because of this error.

Error Code: D0078
Desription: No Account
Resoution: Code reported by host processor. Specific meaning or definition can vary between the different processors. Contact your ISO or processor if you encounter an excessive amount of these errors, or you cannot complete a test transaction because of this error.

Error Code: D0080
Desription: Invalid Date
Resoution: Code reported by host processor. Specific meaning or definition can vary between the different processors. Contact your ISO or processor if you encounter an excessive amount of these errors, or you cannot complete a test transaction because of this error.

Error Code: D0081
Desription: Time out: response not received in time allowed (SHAZAM switch-in-front (SIF) terminals).
Resoution: Code reported by host processor (Shazam). Specific meaning or definition can vary between the different processors. Contact your ISO or processor if you encounter an excessive amount of these errors, or you cannot complete a test transaction because of this error.

Error Code: D0082
Desription: Cashback limit exceeded.
Resoution: Code reported by host processor. Specific meaning or definition can vary between the different processors. Contact your ISO or processor if you encounter an excessive amount of these errors, or you cannot complete a test transaction because of this error.

Error Code: D0083
Desription: Cannot verify PIN
Resoution: Code reported by host processor. Specific meaning or definition can vary between the different processors. Contact your ISO or processor if you encounter an excessive amount of these errors, or you cannot complete a test transaction because of this error.

Error Code: D0084
Desription: Processor not available; acquirer processor unable to send message
Resoution: Code reported by host processor. Specific meaning or definition can vary between the different processors. Contact your ISO or processor if you encounter an excessive amount of these errors, or you cannot complete a test transaction because of this error.

Error Code: D0086
Desription: Cannot verify PIN
Resoution: Code reported by host processor. Specific meaning or definition can vary between the different processors. Contact your ISO or processor if you encounter an excessive amount of these errors, or you cannot complete a test transaction because of this error.

Error Code: D0090
Desription: Cutoff complete for terminal; cannot process prior days business
Resoution: Code reported by host processor. Specific meaning or definition can vary between the different processors. Contact your ISO or processor if you encounter an excessive amount of these errors, or you cannot complete a test transaction because of this error.

Error Code: D0091
Desription: Bank unavailable
Resoution:Code reported by host processor. Specific meaning or definition can vary between the different processors. Contact your ISO or processor if you encounter an excessive amount of these errors, or you cannot complete a test transaction because of this error.

Error Code: D0092
Desription: System unavailable
Resoution: Code reported by host processor. Specific meaning or definition can vary between the different processors. Contact your ISO or processor if you encounter an excessive amount of these errors, or you cannot complete a test transaction because of this error.

Error Code: D0093
Desription: Transaction serial number mismatch
Resoution: Verify all programming, contact host processor

Error Code: D0094
Desription: Record format mismatch
Resoution: Verify all programming, contact host processor

Error Code: D0095
Desription: Routing ID mismatch
Resoution: Verify Routing ID number - contact host processor

Error Code: D0096
Desription: Terminal ID mismatch
Resoution: Verify Terminal ID number - contact host processor

Error Code: D0097
Desription: Response type mismatch (reversal)
Resoution: Verify all programming, contact host processor

Error Code: D0098
Desription: Response type mismatch (day-close)
Resoution: Verify all programming, contact host processor

Error Code: D0099
Desription: Response type mismatch (Configuration)
Resoution: Verify all programming, contact host processor

Error Code: D009A
Desription: Response type mismatch (Withdrawal, Balance, Transfer)
Resoution: Verify all programming, contact host processor

Error Code: D009B
Desription: STX omitted
Resoution: Verify all programming, contact host processor

Error Code: D009C
Desription: ETX omitted
Resoution: Verify all programming, contact host processor

Error Code: D009D
Desription: FS omitted (after response code)
Resoution: Verify that version of Mini-Bank Software matches host processor. Contact host processor

Error Code: D009E
Desription: FS omitted (after retrieval reference number)
Resoution: Verify all programming. Verify that version of Mini-Bank Software matches host processor. Contact host processor

Error Code: D009F
Desription: FS omitted (after system trace audit number)
Resoution: Verify all programming. Verify that version of Mini-Bank Software matches host processor. Contact host processor

Error Code: D00A0
Desription: FS omitted (after account balance)
Resoution: Verify all programming. Verify that version of Mini-Bank Software matches host processor. Contact host processor

Error Code: D00A1
Desription: FS omitted (after available balance)
Resoution: Verify all programming. Verify that version of Mini-Bank Software matches host processor. Contact host processor

Error Code: D00A2
Desription: FS omitted (after available balance)
Resoution: Verify all programming. Verify that version of Mini-Bank Software matches host processor. Contact host processor

Error Code: D00A3
Desription: FS omitted (after authorization response text)
Resoution: Verify all programming. Verify that version of Mini-Bank Software matches host processor. Contact host processor

Error Code: D00A4
Desription: ETX is in wrong place
Resoution: Verify all programming. Verify that version of Mini-Bank Software matches host processor. Contact host processor

Error Code: D00A5
Desription: FS omitted (after total cash dispense amount in day close)
Resoution: Verify all programming. Verify that version of Mini-Bank Software matches host processor. Contact host processor

Error Code: D00A6
Desription: FS omitted (after total non cash dispense amount in day close)
Resoution: Verify all programming. Verify that version of Mini-Bank Software matches host processor. Contact host processor

Error Code: D00A7
Desription: FS omitted (after surcharge amount in day close message)
Resoution: Verify all programming. Verify that version of Mini-Bank Software matches host processor. Contact host processor

Error Code: D00A8
Desription: FS omitted (after surcharge amount in configuration message)
Resoution: Verify all programming. Verify that version of Mini-Bank Software matches host processor. Check that Dual Master Key is disabled (non Coredata). Contact host processor

Error Code: D00A9
Desription: ETX omitted (from configuration message)
Resoution: Verify all programming. Verify that version of Mini-Bank Software matches host processor. Contact host processor

Error Code: D0300
Desription: Modem is not responding
Resoution: Use diagnostic or modem test to test modem. If error is persistent, modem may be defective.

Error Code: D1000
Desription: No Connection
Resoution: Use diagnostic or modem test to test modem. If error is persistent, modem may be defective.

Error Code: D1100
Desription: ENQ not received from host
Resoution: Verify all programming. Verify that version of Mini-Bank Software matches host processor. Contact host processor

Error Code: D1200
Desription: Transmission error
Resoution: Use diagnostic or modem test to test modem. If error is persistent, modem may be defective

Error Code: D1300
Desription: NAK sent 3 times to host
Resoution: Verify host phone number - See D170x. If persistent, it could be a defective modem.

Error Code: D1500
Desription: Modem connection time out - host not responding
Resoution: Verify host phone number - verify modem speed - See D170x. If consistent, it can be a defective modem

Error Code: D1702
Desription: Modem connection error
Resoution: Phone line connected to ATM will not support data communication. In line filter may help this. Excessive EMI emissions from outside source (neon sign, freezer)are likely causes. This can also be a problem with programming, check all programming (especially Dual Master Key setting and Host Processor Mode).

Error Code: D1704
Desription: Modem connection error
Resoution: Phone line connected to ATM will not support data communication. In line filter may help this. Excessive EMI emissions from outside source (neon sign, freezer)are likely causes. This can also be a problem with programming, check all programming (especially Dual Master Key setting and Host Processor Mode).

Error Code: D1706
Desription: Modem connection error
Resoution: Phone line connected to ATM will not support data communication. In line filter may help this. Excessive EMI emissions from outside source (neon sign, freezer)are likely causes. This can also be a problem with programming, check all programming (especially Dual Master Key setting and Host Processor Mode).

Error Code: D170x
Desription: Modem cannot support connection - excessive line noise (usually D1704/06)
Resoution: Phone line connected to ATM will not support Data-communication. In line filter may fix this. Excessive EMI emissions from outside source (neon sign, freezer). This can also be a problem with programming, check all programming (especially Dual Master Key setting and Host Processor Mode).

Error Code: D1800
Desription: No dial tone
Resoution: Verify that incoming phone line is plugged into "Line" rather than "Phone" on mainboard. Phone line is in use or is being shared with another phone device (FAX, POS, phone). NOTE: This error occurs only if there is no dial tone at the mainboard.

Error Code: D1900
Desription: No answer
Resoution: Verify host phone number - See D170x, there is no answer from the host modem.

Error Code: D2000
Desription: Phone line Busy
Resoution: Verify host phone number - call line with handset and check for busy signal - See D170x. ATM modem is receiving a busy signal when it dials out.

Error Code: D2100
Desription: Modem initialization error
Resoution: Check modem in diagnostics or modem test. If persistent, it could be a defective modem. Note: If the modem is defective, this error will most likely occur frequently. One or two instances of this error does not usually indicate a defective part.

Error Code: D2200
Desription: EOT not received from host
Resoution: Verify all programming. Verify that version of Mini-Bank Software matches host processor. Contact host processor

Error Code: E000x
Desription: RMS port failure, response time out, modem failure, no dial tone
Resoution: Verify RMS settings (Host Setup) - See D170x

Error Code: F0001
Desription: Current Number of Bills is 0
Resoution: Load notes into the cash cassette - use Add Cassette function in Settlement

Error Code: F0002
Desription: No Surcharge Owner set
Resoution: Set Surcharge owner - (Customer Setup)

Error Code: F0003
Desription: No Surcharge Amount
Resoution: Set Surcharge amount - (Customer Setup)

Error Code: F0004
Desription: No refresh timer set when advertisement is enabled
Resoution: Set refresh timer - (Customer Setup)

Error Code: F0005
Desription: No Advertisement text when advertisement is enabled
Resoution: Set Advertisement text - (Customer Setup)

Error Code: F0006
Desription: Dispense limit set error (must be less than 25 notes)
Resoution: Set Dispense limit - (Transaction Setup)

Error Code: F0007
Desription: Denomination Set error
Resoution: Valid Denominations are $10, $20, $50, $100 - (Transaction Setup)

Error Code: F0008
Desription: Fast Cash Set error (cannot exceed dispense limit)
Resoution: Check fast cash settings (Transaction Setup)

Error Code: F0009
Desription: Master Key index is invalid
Resoution: Check Master Key index - verify checksum (Host Setup)

Error Code: F000A
Desription: Master Key is empty
Resoution: Check Master Key checksum - reinject key (Host Setup)

Error Code: F000B
Desription: Host Telephone Number is not set
Resoution: Set Host Telephone Number - (Host Setup)

Error Code: F000C
Desription: Error Retry timer is not set
Resoution: Set Error retry timer (Host Setup)

Error Code: F000D
Desription: RMS Password is not set when RMS is enabled
Resoution: Set RMS Password - (Host Setup)

Error Code: F000E
Desription: RMS phone number is not set when RMS send is enabled
Resoution: Set RMS Phone number - (Host Setup)

Error Code: F000F
Desription: Terminal ID is not set
Resoution: Set Terminal ID number - (Host Setup)

Error Code: F0010
Desription: Routing ID is not set
Resoution: Set Routing ID number - (Host Setup)

Error Code: F0011
Desription: Master Key Serial number is not set
Resoution: Set Master Key serial number - (Host Setup)

Error Code: F0013
Desription: NVRAM Failure
Resoution: Fatal error, defective memory chip. Replace Mainboard

Error Code: F0014
Desription: NVRAM Failure
Resoution: Fatal error, defective memory chip. Replace Mainboard

Error Code: W0001
Desription: WebRMS failed to dial into the ATM
Resoution: This does not mean that the ATM is down; it's a warning message that WebRMS could not dial into the ATM after three attempts during its daily scheduled dial-in period. Make sure the ATM is turned on, the phone line fits securely on both ends, and not shared with a voice phone nor experiences static.

Error Code: W0002
Desription: WebRMS low cash warning
Resoution: This is a courtesy alert warning, along with an email message, that you requested to receive when the total bill count is under a certain amount. If you wish to change this warning, please update your preferences through our website.

Error Code: W0003
Desription: WebRMS could not retrieve the local ATM time
Resoution: Although webRMS successfully retrieved the journal information, it could not find the ATM's local time. (This is equivalent to the "-1/-1/-001" error when using Windows RMS). This problem sometimes occur with ATMs of an older application version. Make sure you are running the latest application version.

Error Code: W0004
Desription: The ATM time, as set in the Operator Function Menu, is incorrect
Resoution: WebRMS has detected that the ATM probably has incorrect date and time settings. You will need to physically go to the ATM location and manually reset the correct date with the Master Password.

Error Code: W0005
Desription: WebRMS coincidentally detected that the ATM was in Operator mode at the time the ATM was dialed into.
Resoution: This is not an error in particular, but a simple warning that someone was locally on-site at the ATM, and used its Operator Function menu.

Error Code: W0006
Desription: WebRMS has failed to dial into the ATM consecutively for more than 3 days.
Resoution: Check with the merchant and/or site owner to ensure that the ATM is turned on at all times, and that the ATM is not sharing the line with another device.

© 2009, Accent ATM Pros, Inc. All Rights Reserved | 3221 Tyrone Blvd. N St. Petersburg, FL 33710
